1. The approximate operating weight of the unit is:
09DK-054— ________► 1695 lb [769 kg]
09DK-054-C------------- »■ 1983 lb [900 kg]
09DK-064— ------------- »• 1845 lb [837 kg]
09DK-064-C------------- »-2278 lb [1033 kg]
2. Unit must have clearances for airflow as follows:
Top — Do not restrict in any way.
Ends — 5 ft [1524 mm]
Sides — 6 ft [1829 mm]
3. All units are shipped with a capacity split tubing kit. This kit may be used by
the field to obtain 100%, 50%/50% and 67%/33% capacity splits. To obtain
a 33%/33%/33% capacity split, coils must be manifolded by the field. Coils'
are factory circuited for a 33%/33%/17%/17% capacity split.
NOTES:
CONTROL BOX
END
UNIT DIMENSION Y DIMENSION X
OPERATING CORNER WEIGHTS
A B C D
09DK-054—
3'-6 11/16”
[1084 mm] 4'-1/8"
[1222 mm]
452 lb
[205 kg]
425 lb
[193 kg]
396 lb
[180 kg]
422 lb
[191 kg]
09DK-054-C
3'-6 7/8"
[1090 mm]
4'-5/16"
[1227 mm]
524 lb
[238 kg]
497 lb
[225 kg]
468 lb
[212 kg]
494 lb
[224 kg]
09DK-064—
3'-6 3/4"
[1087 mm]
4'-3/16"
[1224 mm]
489 lb
[222 kg]
462 lb
[210 kg]
434 lb
[197 kg]
459 lb
[208 kg]
09DK-064-C
3’-7 1/8"
[1095 mm]
4'-1/2"
[1232 mm]
598 lb
[271 kg]
571 lb
[259 kg]
542 lb
[246 kg]
568 lb
[258 kg]
C A P A C I T Y S P L I T
C O N N E C T I O N S
T Y P E N
0.5
S I Z E
100
%
H O T G A S
1
/
3
.
5,7 1 1
/
8
’ I . D .
L I Q U I D
2
,
4
.
6,8 7/8
I . D .
50
% /
50
%
H O T G A S
1/3 5,7 1 1
/
8
' I . D .
L I Q U I D
2.4 6.8 7/8
I . D .
67
% /
33
%
H O T G A S
1
.
3,5 7 1 1
/
8
' I . D .
L I Q U I D
2
.
4.5 8 7/8 1
.
0
.
33
% /
33
% /
33
%
H O T G A S
1 7 3,51 1
/
8
' I . D .
L I Q U I D
2 a 4.5 7/8
I . D .
33
% /
33
% /
17
% /
17
%
H O T G A S
1 7 3 5 1 1
/
8
' I . D .
L I Q U I D
2 8 4 6 7/8
I . D .
T-A 1/2'-
C224 7rain3
BASE OVERALL
Fig. 3 — Dimensions; 054 and 064 Units
