Table 4 — 09DK Electrical Data
NAMEPLATE
V-PH-HZ
SUPPLY VOLTAGE* FAN MOTORS
09DK
Min Max
MCA MOCP NO. FANS
Total Kw
(Fan no.)
FLA for ea. fan
054
-500 208/230-3-60 187 254 23.2 25 4 6.2 (1,2) 5.5 (3,4) 5.4
-600 460-3-60 414 508 11.7 15 4 6.2 (1,2) 2.8 (3,4) 2.7
-100 575-3-60 518 632 14.5 15 4 6.2 (1-4) 3.4
-200 380-3-60 342 418 166 20 4 62 (1-4) 3.9
-900 380/415-3-50 342 440 128 15 4 62 (1-4) 3.0
064
-500 208/230-3-60 187 254 23.2 25 4 6.2 (1,2) 5 5 (3,4) 5 4
-600 460-3-60 414 508 11 7 15 4 62 (1,2) 2.8 (3,4)2 7
-100 575-3-60 518 632 14.5 15 4 62 (1-4) 3.4
-200 380-3-60 342 418 166 20 4 6.2 (1-4) 3.9
-900 380/415-3-50 342 440 128 15 4 6.2 (1-4) 3.0
074
-500 208/230-3-60 187 254 34 0 35 6 93 (1,2) 5.5 (3-6) 5.4
-600 460-3-60 414 508 17.1 20 6 93 (1,2) 2.8 (3-6) 2.7
-100 575-3-60 518 632 21.3 25 6 93 (1-6)3 4
-200 380-3-60 342 418 24.4 25 6 93 (1-6)3 9
-900 380/415-3-50 342 440 18.8 20 6 9.3 (1-6)3 0
084
-500 208/230-3-60 187 254 34.0 35 6 9.3 (1,2) 5.5 (3-6) 5 4
-600 460-3-60 414 508 17.1 20 6 93 (1,2)2 8(3-6) 2.7
-100 575-3-60 518 632 21 3 25 6 9.3 (1-6) 3.4
-200 380-3-60 342 418 24 4 25 6 9.3 (1-6) 3.9
-900 380/415-3-50 342 440 188 20 6 93 (1-6) 3.0
Control Circuit Information
09DK
ALL
UNITS
CONTROL POWER
V-PH-HZ
SUPPLY
VOLTAGE*
OVERCURRENT
PROTECTION
AMPS
-500 115-1-60 103 127 10
-600 115-1-60 103 127 10
-100 115-1-60 103 127 10
-200 230-1-60 207 253 10
-900 230-1-50 207 253 10
LEGEND
FLA
MCA — Full Load Amps
— Minimum Circuit Amps; Used for wire sizing
(Complies with NEC Sectien 430-24)
MOCP — Maximum Overcurrent Protection
NEC — National Electrical Code
'Units are suitable for use on electrical systems where voltage sup­
plied to the unit terminals is within listed minimum and maximum
limits.
NOTES:
1. Maximum allowable phase imbalance: Voltage ± 2%; Amps ± 10%
2. Maximum incoming wire size for power circuit is 2/0 max
3. Control Circuit: Uses no. 8 screws for wire connections at the ter­
minal block.
4. 100 va is required for the 09DK054-084 control circuit
