HEATING & COOLING
09DK054-084
Air-Cooled Condenser Units
50/60 Hz
à
Installation, Start-Up and
Service Instructions
Air-Cooled Packages
CONTENTS
SAFETY CONSIDERATIONS ...
Page
,.. 1
1-28
INSTALLATION .................................................
Step 1 — Complete Pre-Installation
Checks ............................................................................. 1
Step 2 — Rig and Place Unit ..........................................4
• RIGGING
• PLACING THE UNIT
Step 3 — Complete Refrigerant Piping..................... 7
• GENERAL
• COIL REFRIGERANT PIPING INSTALLATION
• TUBING PACKAGE INSTALLATION
• THREE AND FOUR COIL SPLIT, COIL
CIRCUITING APPLICATIONS; 054-084 UNITS
• REFRIGERANT LINE SIZING
• LIQUID SHUTOFF VALVE AND SIGHT GLASS
• PRESSURE RELIEF
• REFRIGERANT RECEIVER
• LIQUID LIFT
Step 4 — Complete Electrical
Connections..................................................................21
• GENERAL
• FIELD CQNNECTIONS
• MAIN POWER WIRING
• CONTROL CIRCUIT POWER WIRING
• GENERAL WIRING NOTES
• DESCRIPTION OF CONTROLS
Step 5 — Add Accessories as Needed .....................28
START-UP.......................................................................... 29
System Evacuation and
Dehydration ..................................................................29
Charging Procedure........................................................29
Check Operation of Condenser Fan Motor
Controls and Rotation of Fans................................ 29
SERVICE ...................................................................... 29-31
Cleaning Condenser Coils ........................................ 29.
Condenser Fans ..............................................................29
Lubrication ....................................................................... 29
Head Pressure Control ..................................................29
• FAN CYCLING
SAFETY COIVISIDERATIOIMS
Installing, starting up, and servicing air-conditioning equip
ment can be hazardous due to system pressures, electrical
components, and equipment location (roofs, elevated struc
tures, etc.).
Only trained, qualified installers and service mechanics
should install, start up, and service this equipment (Fig. 1).
Untrained personnel can perform basic maintenance func
tions such as cleaning coils. All other operations should be
performed by trained service personnel.
Fig. 1 — Model 09DK (084 Shown)
When working on the equipment, observe precautions in
the literature and on tags, stickers, and labels attached to
the equipment.
Follow all safety codes. Wear safety glasses and work
gloves. Keep quenching cloth and fire extinguisher nearby
when brazing. Use care in handling, rigging and setting bulky
equipment.
See Tables lA and IB for Physical Data.
ELECTRIC SHOCK HAZARD
Separate power sources (main and control cir
cuit power) are used for these units. Be sure
both main and control circuit powers are dis
connected before servicing.
INSTALLATION
Step 1 — Complete Pre-Installation Checks —
Examine for damage incurred during shipment. File claim
immediately with transit company if damage is found. Ver
ify that the nameplate electrical requirements match the avail
able power supply. Check the shipment for completeness.
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book 12
PC 111
Catalog No 530-953
Printed in U.S A
Form 09DK-4SI
Pg 1
4-93
Replaces: New
Tab 4a
