LEFTSIDE COILS
RIGHT SIDE COILS
054,064
PERCENT CAPACITY
LINE TYPE
COIL CONNECTION
COIL CONNECTION
TUBING CONNECTION
SPLIT
NUMBER
in.-ODM*
in. ODMf
100
Hot Gas
1,3,5,7
1 1/8
1 5/8
Liquid
2,4,6,8
7/8
1 1/8
50/50
Hot Gas
1,3/5,7
1 1/8
1 3/8
1 3/8
Liquid
2,4/6,8
7/8
7/8
7/8
66/34
Hot Gas
1,3,5/7
1 1/8
1 3/8
1 1/8
Liquid
2,4,6/8
7/8
7/8
7/8
34/34/32
Hot Gas
Liquid
1/7/3,5
2/8/4,6
1 1/8
7/8
(3) 1 1/8
(3) 7/8
34/34/16/16
Hot Gas
Liquid
1/7/3/5
2/8/4/6
1 1/8
7/8
•Connection sizes reflect size of each coil header nozzle.
fA tubing package is factory supplied to facilitate field piping installation for the 100, 50/50 and 66/34 capacity split applications See installation instructions for more
information
074
PERCENT CAPACITY
LINE TYPE
COIL CONNECTION
COIL CONNECTION
TUBING CONNECTION
SPLIT
NUMBER
in.-ODM*
in.-ODMf
100
Hot Gas
1,3,5,7
1 3/8
2 1/8
Liquid
2,4,6,8
7/8
1 1/8
50/50
Hot Gas
1,3/5,7
1 3/8
1 5/8
1 5/8
Liquid
2,4/6,8
7/8
7/8
7/8
68/32
Hot Gas
1,3,5/7
1 3/8
1 5/8
1 3/8
Liquid
2,4,6/8
7/8
7/8
7/8
32/32/36
Hof Gas
Liquid
1/7/3,5
2/8/4,6
1 3/8
7/8
(3) 1 3/8
(3) 7/8
32/32/18/18
Hot Gas
Liquid
1/7/3/5
2/8/4/6
1 3/8
7/8
•Connection sizes reflect size of each coil header nozzle
tA tubing package is factory supplied to facilitate field piping installation for the 100, 50/50 and 68/32 capacity split applications. See installation instructions for more
information.
084
PERCENT CAPACITY
LINE TYPE
COIL CONNECTION
COIL CONNECTION
TUBING CONNECTION
SPLIT
NUMBER
in.-ODM*
in.-ODMt
100
Hot Gas
1,3,5,7
1 3/8
2 1/8
Liquid
2,4,6,8
7/8
1 1/8
50/50
Hot Gas
1,3/5,7
1 3/8
1 5/8
1 5/8
Liquid
2,4/6,8
7/8
7/8
7/8
67/33
Hot Gas
1,3,5/7
1 3/8
1 5/8
1 3/8
Liquid
2,4,6/8
7/8
1 1/8
7/8
33/33/33
Hot Gas
1/7/3,5
1 3/8
(3) 1 3/8
Liquid
2/8/4,6
7/8
(3) 7/8
33/33/17/17
Hot Gas
Liquid
1/7/3/5
2/8/4/6
1 3/8
7/8
•Connection sizes reflect size of each coil header nozzle
tA tubing package is factory supplied to facilitate field piping installation for the 100, 50/50 and 67/33 capacity split applications See installation instructions for more
information.
Fig. 9 — Coil Connection Data
