Table IA — Physical Data 60 fìz
English
09DK 054 064 074 084
NOMINAL TONS 50 60 70 80
OPERATING WEIGHT-lb
Cu-AI* 1695 1845 2200 2421
Cu-Cut 1983 2278 2617 3099
SHIPPING WEIGHT-lb“
Cu-AI‘ 2010 2136 2521 2725
Cu-Cut 2298 2569 2938 3403
REFRIGERANTS R-134A, R-22, R-12, R-500, R-502
NOMINAL HEAT REJECTION
(TONS)tt
65.8 78.6 95.4 103.5
CONDENSER FANS
No. of Blades 4 4 4 4
No. of Fans 4 4 6 6
Fan Diameter-In. 30 30 30 30
AIrflow-cfm 35,000 35,000 52,000 51,000
Fan Speed-rpm 1140 1140 1140 1140
Fan Motor-hp 1 1 1 1
CONDENSER COILS
Quantity 4 4 4 4
FIns/in. 17 17 17 17
No. of Rows 2 3 2 3
Total Face Area (sq ft) 80.5 80.5 116.7 1 1 6 7
TD — Temperature Difference = Saturated Condensing Temperature - Entering-Air Temperature
‘Copper tubes and aiuminum fins.
TCopper tubes and copper fins.
“Packaging option includes skid and coil protection.
ttNominal heat rejection based on refrigerant R-22, 15° F subcooling, and a 30° F temperature difference (TD).
SI
09DK 054 064 074 084
NOMINAL kW 175.7 210.9 246.0 281.2
OPERATING WEIGHT-kg
Cu-AI* 769 837 998 1098
Cu-Cut 900 1033 1187 1406
SHIPPING WEIGHT-kg“
Cu-AI* 912 969 1144 1236
Cu-Cut 1042 1165 1333 1544
REFRIGERANTS R-134A, R-22, R-12, R-500, R-502
NOMINAL HEAT REJECTION
(kW)tt
231.3 276 2 335.3 363 8
CONDENSER FANS
No. of Blades 4 4 4 4
No. of Fans 4 4 6 6
Fan DIameter-mm 762 762 762 762
AIrflow-L/s 16 520 16 520 24 540 24 070
Fan Speed-r/s 19 19 19 19
Fan Motor-kW .746 .746 .746 746
CONDENSER COILS
Quantity 4 4 4 4
FIns/m 669 • 669 669 669
No. of Rows 2 3 2 3
Total Face Area (sq m) 7.5 75 10.84 10.84
TD — Temperature Difference = Saturated Condensing Temperature - Entering-Air Temperature
‘Copper tubes and aluminum fins.
tCopper tubes and copper fins.
“Packaging option includes skid and coil protection
ttNominal heat rejection based on refrigerant R-22, 8.3° C subcooiing, and a 16.7° C temperature difference (TD).
