Table 1B — Physical Data 50 Hz
English
09DK 054 064 074 084
NOMINAL TONS 50 60 70 80
OPERATING WEIGHT-lb
Cu-AI* 1695 1845 2200 2421
Cu-Cut 1983 2278 2617 3099
SHIPPING WEIGHT-lb"
Cu-AI* 2010 2136 2521 2725
Cu-Cut 2298 2569 2938 3403
REFRIGERANTS R-134A, R-22, R-12, R-500, R-502
NOMINAL HEAT REJECTION
(TONS)tt
65.8 78.6 95 4 103.5
CONDENSER FANS
No. of Blades 6 6 6 6
No. of Fans 4 4 6 6
Fan DIameter-ln. 30 30 30 30
AIrflow-cfm 35,000 35,000 52,000 51,000
Fan Speed-rpm 950 950 950 950
Fan Motor-hp 1 1 1 1
CONDENSER COILS
Quantity 4 4 4 4
Fins/in. 17 17 17 17
No. of Rows 2 3 2 3
Total Face Area (sq ft) 80.5 80.5 116.7 1167
TD — Temperature Difference = Saturated Condensing Temperature - Entering-Air Temperature
'Copper tubes and aluminum fins
tCopper tubes and copper fins.
"Packaging option includes skid and coil protection.
ttNominal heat rejection based on refrigerant R-22, 15° F subcooling, and a 30° F temperature difference (TD).
SI
09DK 054 064 074 084
NOMINAL kW 175 7 210 9 246 0 281 2
OPERATING WEIGHT-kg
Cu-AI* 769 837 998 1098
Cu-Cut 900 1033 1187 1406
SHIPPING WEIGHT-kg"
Cu-AI* 912 969 1144 1236
Cu-Cut 1042 1165 1333 1544
REFRIGERANTS R-134A, R-22, R-12,R-500, R-502
NOMINAL HEAT REJECTION
(kW)tt
231.3 276.2 335.3 363.8
CONDENSER FANS
No. of Blades 6 6 6 6
No. of Fans 4 4 6 6
Fan DIameter-mm 762 762 762 762
AIrflow-L/s 16 520 16 520 24 540 24 070
Fan Speed-r/s 15.8 15.8 15.8 15.8
Fan Motor-kW .746 746 746 .746
CONDENSER COILS
Quantity 4 4 4 4
Fins/m 669 669 669 669
No. of Rows 2 3 2 3
Total Face Area (sq m) 7.5 7.5 10 84 10 84
TD — Temperature Difference = Saturated Condensing Temperature - Entering-Air Temperature
•Copper tubes and aluminum fins
tCopper tubes and copper fins
"Packaging option includes skid and coil protection.
ttNominal heat rejection based on refrigerant R-22, 8 3° C subcooling. and a 16.7° C temperature difference (TD)
