Tuffy Security 304 User Manual
Installation instructions, 304 mounting kit parts, 304 shipping package

Page 1 of 7 – 10/17/2013
INSTALLATION INSTRUCTIONS
#304 Tactical Security Drawer Mounting Kit
Fits: Ford Interceptor Sedan (2012-up)
(This kit is designed to mount on the rear cargo drawer sold separately)
Please read and fill out the enclosed warranty registration card to activate your warranty.
Table of Contents:
Vehicle
Standard Drawer Enclosure Size
Pages
General Mounting Directions (All Vehicles)
2
Ford Interceptor Sedan (2012-up)
#167-420220080-000-01
3-7
#304 Auxiliary Tray Instructions
7
#304 Mounting Kit Parts
#16 (1) Lower Drivers Side
Assembly(Pre-assembled)
#17 (1) Lower Passenger Side
Assembly(Pre-assembled)
#8 (1) Electronics Tray
#2 (1) Upper Support Plate
Drivers Side
#
11 (2) Tray Mount Bracket
Drivers Side
#1 (1) Upper Support Plate
Passenger Side
#
10 (2) Tray Mount Bracket
Passenger Side
#9 (1) Auxiliary Tray
(Optional)
#304 Shipping Package
#12.1 (4) 5/16x3/4”
Carriage Bolts
#12.2 (8) 5/16x1” Bolts
#12.3 (21) 5/16 Washers
#12.4 (13) 5/16
Nylock Nuts
#12.5 (4) 5/16”x1”
Self-Drilling Screw
Parts used which are included with the drawer assembly:
Enclosure
Drawer
(1) Mounting Bracket
Parts used from the drawer shipping package (Included with drawer):
#5.2.4 (4) 5/16-18x7/8” Bolts
#5.2.2 (4) 5/16 Nuts
#5.2.3 (8) 5/16 Narrow OD Washers
