Tuffy Security 027 - Manual

Page 1 of 2 - 1/28/2008 – Rev122006
INSTALLATION INSTRUCTIONS
Universal Security Lockbox Part #027
Please read and fill out the enclosed warranty registration card to activate your warranty.
Shipping Package
(1) Mounting Bracket
(4) 5/16” x 1 ¼” Bolts (4) 5/16” Washers (4) 5/16” Nuts
Tools Needed
o Power drill
o 3/8” drill bit
o (2) ½” wrenches
Installation
Read all instructions before starting installation
If the lockbox will be mounted under the hood on the wheel well, attach the mounting
bracket to the lockbox first (See FIGURE 2).
1. Place the lockbox in the vehicle
If the lockbox will be mounted in a 87-95 Wrangler no drilling is required.
2. With the lockbox in place mark the mounting holes.
Warning! Make sure there is nothing under the vehicle that will be damaged while drilling
3. Remove the lockbox and drill out the marked spots.
4. Fasten the lock box to the vehicle using the 5/16” hardware provided. (See FIGURE 1)
5. Lock it up!
