INSTALLATION INSTRUCTIONS
TJ Glovebox Part # 049
Please read and fill out the enclosed warranty registration card to activate your warranty.
Tools Needed
‰ #1 Phillips head screwdriver
‰ 7/16” Socket
‰ 1/8” allen wrench
‰ Ratchet for ¼” socket
‰ 3/8” wrench
‰ Drill and ¼” drill bit
Shipping Package
(2) #10 Flat Washers (2)10-32 Locknuts (2)10-32 x 1/2” Button Head Cap Screws
Mounting Directions
1. Remove the factory glovebox from your TJ by gently pulling forward on the plastic tab on the right
side until the tab clears the dash and the box rotates out all the way or by releasing the holding
strap. Gently pull on the glovebox until the plastic hinges release.
2. Remove the factory lock catch at the top of the opening by unscrewing the two Phillips head
screws, save screws.
3. Remove the eight Phillips head screws that attach the steel framework to the dash, save screws.
4. Cut and stick the neoprene strip across the top and down the sides of the Tuffy glovebox frame
(Where the closed door will meet up with the frame)
5. Bolt the Tuffy glovebox in by fastening the 10 original screws into the original mounting holes
(Eight around the face of the new frame and two behind the new lock catch on the frame). It is
easiest to just start all the screws at first then tighten them all the way down.
6. For security two holes will need to be drilled in the dash frame. The two extra holes in the new
lock catch on the frame can be used as pilots to drill these holes in your dash frame.
WARNING! Be careful while drilling and avoid drilling into air ducts.
