12.3. Output Unit Settings of the Packet Audio Signal
Packet audio signals can be transmitted not only to the PC but also to the TOA Network Audio Adapters NX-
100 and NX-100S via an Ethernet cable. In this case, it is possible to set which tuner unit's audio signals to be
output to the network.
12.3.1. Setting procedures
Step 1. Display "9 NETWORK" in the Operation menu display
Step 2. Press the Right key to go to NETWORK MENU.
Step 3. Press the Up and Down keys to go to MONITOR UNIT.
Step 4. Press the Right key to go to the tuner unit setting screen.
Step 5. Select the tuner unit to be output using the Up and Down keys
Step 6. Press the SET key.
The setting is confirmed and an asterisk
" " is displayed before the tuner unit on
the screen.
The mixing output of Unit 1 and Unit 2 as well as the individual outputs of Unit 1 and Unit 2 can be selected as
a Packet audio output.
Note
To use this function, network setting and the NX-100 or NX-100S settings must be performed in advance.
Settings can be made at the receiver in Local mode and from the PC in Remote mode.
M O N I T O R U N I T
[ U N I T 2 ]
12.4. IP Address check
Checks the receiver’s IP Address.
12.4.1. Setting procedures
Step 1. Display “9 NETWORK” in the Operation menu display.
Step 2. Press the Right key to go to NETWORK MENU.
Step 3. Select “IP ADDRESS” using the Up
and Down keys, then press the Right
key.
Receiver’s IP address is displayed.
12.5. mAC Address check
Checks the receiver’s MAC Address (network card unique identifier).
12.5.1. Setting procedures
Step 1. Display “9 NETWORK” in the Operation menu display.
Step 2. Press the Right key to go to NETWORK MENU.
Step 3. Select “MAC ADDRESS” using the Up
and Down keys, then press the Right
key.
Receiver’s MAC address is displayed.
I P A D D R E S S
1 0 . 1 5 4 . 2 3 . 9 5
M A C A D D R E S S
0 0 1 5 - 5 F 9 2 - A 0 9 5
