LH 665 VRT O PERATORS MANUAL A PPLICATION CONTROL , OPERATION
LH A GRO 3.7
CHANGING BETWEEN THE ENCODED FIELD AND LOAD NUMBERS
Small arrows are shown to the left of the field/load number (screen section A). The
field numbers can be paged through if the arrows are to the left of the field
number. If however the arrows are to the left of the load number then paging
though the loads is possible.
CHANGE FIELD
If the small arrows are not to the left of the field number, pressing the FIELD key
allows paging through all fields using the ARROW UP/DOWN keys.
Press the ACCEPT key to accept the field.
CHANGE LOAD
If the small arrows are not to the left of the load number, pressing the LOAD key
allows paging through all fields using the ARROW UP/DOWN keys.
Press the ACCEPT key to accept the load.
SELECTING THE TARGET FILE
To select the file used for the application task, do as follows:
If the LH 665 is to be used for logging data only and not controlling the application
rate, select NONE when selecting the target file.
Step Key Procedure
1 Press the MENU key until the following menu selection keys
appear at the bottom of the display (screen section C):
FIELD LOAD SHOW MAP OPTIONS
2
FIELD Press the FIELD key twice.
3
VIEW
CONFIG
Press the VIEW CONFIG key.
4
EDIT
TGT FILE
Press the EDIT TGT FILE key.
5
ACCEPT
Select the target file using the ARROW UP/DOWN keys and
press the ACCEPT key (the file information can be viewed by
pressing the VIEW INFO key).
6
ACTIVE
ON/OFF
Press the ACTIVE ON/OFF key and a "tick" will appear in
the ACTIVE box on the display.
7
EXIT
Press the EXIT key.
8
ACCEPT
Press the ACCEPT key.
