SKE-SRM
151267 7-5
7.3.3 Remote Microphone Operation
Use the mic gain on the board to adjust audio to desired level. See Figure 7-4 for mic gain
location. The system can support a maximum of one remote microphone.
Table 7-2 describes the remote microphones LEDS.
Main mic on the SKE-450 overrides the remote mic.
In normal mode, remote microphone can be used for emergency use only. Voice will be
broadcasted via the main panel.
In alarm mode, the remote microphone can be used to interrupt any prerecorded messages to
allow manual evacuation. The remote microphone will operate in an "ALL-CALL" mode.
Table 7-2: LED Descriptions
LED Color State Meaning
Green
On The remote microphone has DC power.
Off No DC power.
Yellow
On
Local trouble, indicating that the microphone is
not plug into the remote microphone jack.
Off Microphone is connected properly.
