General alarm control wiring -10, 5 general alarm control wiring – SilentKnight SKE-450 Voice Evacuation Control Panel User Manual
Page 44
SKE-Series Voice Evacuation System Installation/Operation Manual
5-10
151267
5.4.5
General Alarm Control Wiring
This section describes general alarm control wiring as shown in Figure 5-9.
Figure 5-9 General Alarm Control Wiring
Supervised
Power Limited
4.7 k
Ω
UL Listed EOL
Model 7628
