2 terminal strip 1 -4 3.3.3 terminal strip 2 -4 – SilentKnight SKE-450 Voice Evacuation Control Panel User Manual
Page 14
SKE-Series Voice Evacuation System Installation/Operation Manual
3-4
151267
3.3.2
Terminal Strip 1
3.3.3
Terminal Strip 2
Table 3-2: Terminal Strip 1 Description
Terminal Name
Comments
+
Remote Microphone See Section 7.3.2 for details.
-
Active
IN
Neg
Aux Audio (Input)
For recording custom message only. See Section 4.2.2.
In
Enable
FO
Not Used
Com
AC Trouble (Relay) Form C energizes when an AC trouble is detected regardless of
setting of the AC delay switch.
NC
NO
Com
Trouble (Relay)
Form C common trouble relay
NC
NO
Table 3-3: Terminal Strip 2 Description
Terminal Name
Comments
+
CMD2
IN
A short across this input will activate message 2.
–
+
CMD1
IN
A reverse polarity trip from the FACP will activate message 1.
–
+
CMD1
OUT
–
+
SPK IN Used for Class A (Style Z) speaker connections
–
+
SPK
OUT
Used for Class B (Style Y) and Class A (Style Z) speaker connections.
–
