Page 27
Form P-SC, P/N 269822R3, Page 27
Filter Type
Qty
Size
2" Filter
Qty
Size
2" Filter
Qty
Size
2" Filter
Model
SSCBL 400, 800, 1200
SSCBL 500, 600
SSCBL 700, 1050
Disposable
2
16 x 16
104101
1
16 x 25
104099
2
16 x 25
104099
1
16 x 25
104099
1
16 x 20
104097
4
12 x 30
114323
4
12 x 25
114318
4
12 x 20
114317
4
12 x 20
114317
4
12 x 30
114323
4
12 x 25
114318
Permanent
2
16 x 16
104103
1
16 x 20
101620
2
16 x 25
101622
8
12 x 16
114325
4
12 x 20
114321
8
12 x 26
114322
1
16 x 25
101622
1
16 x 25
101622
4
12 x 26
114322
4
12 x 26
114322
Pleated
2
16 x 16
104109
1
16 x 20
104110
2
16 x 25
104112
4
12 x 25
114320
1
16 x 25
104112
4
12 x 32
114324
1
16 x 25
104112
4
12 x 20
114319
4
12 x 20
114319
4
12 x 32
114324
4
12 x 25
114320
Model
SSCDBL 800, 1600
SSCDBL 1000, 1200
SSCDBL 1400
Disposable
4
16 x 16
104101
2
16 x 25
104099
4
16 x 25
104099
2
16 x 25
104099
2
16 x 20
104097
8
12 x 30
114323
8
12 x 25
114318
8
12 x 20
114317
8
12 x 20
114317
8
12 x 30
114323
8
12 x 25
114318
Permanent
4
16 x 16
104103
2
16 x 20
101620
4
16 x 25
101622
16
12 x 16
114325
8
12 x 20
114321
16
12 x 26
114322
2
16 x 25
101622
2
16 x 25
101622
8
12 x 26
114322
8
12 x 26
114322
Pleated
2
16 x 16
104109
2
16 x 20
104110
4
16 x 25
104112
8
12 x 25
114320
2
16 x 25
104112
8
12 x 32
114324
2
16 x 25
104112
8
12 x 20
114319
8
12 x 20
114319
8
12 x 32
114324
8
12 x 25
114320
NOTE: If replacing 1" filters,
replace with locally supplied
filters in the size and type
listed. Quantities listed by
size and arrangements
illustrated on page 26 apply
to both 1" and 2" filters.
Dampers and
Controls -
Applies to Models
SCE and SSCBL
350 - Return
Air Dampers
350 - Outside
Air Dampers
Damper Motor
and Linkage
Code 350 - Damper and Frame Assembly
for 100% Outside Air or Return Air Damp-
ers (includes one frame with damper blades
only)
Model Sizes
P/N
100, 125
105421
150, 175
105422
200, 225
105423
500, 600
250, 300
105424
700, 1050
350
105425
400, 800,
1200
400
105426
Code Description (illustrations on page 28)
P/N
Components by Option AR__ for "BL" Blower Cabinets
(refer to wiring diagram for applicable motorized AR Option)
6
7
8
9*
11*
12*
13*
14*
15
16*
17
18
23*
25
351 Hand Quadrant #14004728-001
103502
X
X
352 Manual Damper Control Bracket (replaces P/N 103488)
143182
X
X
353
Replacement Kit for other 2-position damper actuators including
P/N
66276, 97385, & 209351 labeled J/C M9206-BGB-2)
209423
X
X
X
X
2-Position Actuator, M/H MS8105A1130/U (effective 04/2012 on Model
SSCBL)
263939
X
X
X
354A Auxiliary End Switch only for M/H Damper Motors, #Q607B1067, P/N 113963
354B Auxiliary Switch Kit (2 switches), M/H 220736B, P/N 145881
355 Modulating Damper Motor, #M9175A1051 (no end switch); Motor Support,
P/N 100315
115681
X
X
X
X
X
X
X
356 Optional Modulating Damper Motor, #M9185A1026 (Requires auxiliary
switch kit, P/N 145881, Code 354B.)
202091
X
X
X
X
X
X
X
357 Floating Modulating Damper Motor, #M6194B1011; Motor Support, P/N
100315
115683
X
358 Damper Rod, 1/4 x 12 inches long
11561
X
X
X
X
X
359 Damper Rod, 1/4 x 13 inches long
112554
X
X
X
X
X
X
360 Damper Rod, 1/4 x 18 inches long
11560
X
X
X
X
361 Damper Rod, 1/4 x 17 inches long
112556
X
X
X
X
X
X
X
X
362 Damper Rod, Bent (drawing, page 28)
105420
X
363 Damper Rod Arm
66278
X
364 Damper Arm, M/H #20265
12635
X
X(2)
X
X(2) X(2) X(2)
X(3)
X(2)
X(2) X(3) X(2) X(2) X(2)
365 Ball and Socket, M/H #27518
12636
X(2)
X(2)
X(2) X(4) X(4) X(4)
X(4)
X(4)
X(4) X(4) X(4) X(4) X(4)
366 Crank Arm M/H #221455A
116209
X
X
X
X
X
X
X
X
367 Damper Arm Support Plate
14225
X
368 Damper Arm Adjustment Plate
115687
X
X
X
X
X
X
X
369 Damper Arm Adjustment Plate
142982
X
370 Air Controller Support Bracket
103758
X
X
X
X
X
X
371 Potentiometer, M/H #112894FA
16110
X
X
X
X
372 Mixed Air Controller, M/H #T991A-1004
16109
X
X
X
373 Outdoor Air Controller, J/C#A19AAF-120
126170
X
X
X
374 Null Switch (pressure), Dwyer #1640
88052
X
375 DDC (4-20ma) interface module for use with modulating damper motor, Honeywell Q7230A, P/N 171134
X
