Reznor SSCDBL Parts Manuals - Manual (Page 18)

Form P-SC, P/N 269822R3, Page 18
Unit
Sizes
Motor
Voltage Option
Drive AM Nos. Motor Pulley Blower Pulley Belt *Shaft
Centerline HP Opt (See Key, chart on page 17.) P/N Mfr # Bore P/N Mfr # Bore P/N Qty Mfr #
125
1/4 AL19
AK1 (115/1); AK2 (208/1); AK3 (230/1);
AK5 (208/3); AK6 (230/3); AK7 (460/3)
AM 1, 2, 3, 4 13580 1VL34 5/8 19110 AK84 3/4 16019 1 A40 12.32
AM 5, 6, 7, 8, 9 7962 1VL40 5/8 111607 AK74 3/4 105493 1 A39 12.56
1/3 AL20
AM 2, 3, 4 4074 1VP34 1/2 19110 AK84 3/4 105493 1 A39 11.82
AM 5, 6, 7, 8 13491 1VL40 1/2 111607 AK74 3/4 16018 1 A38 11.56
AM 9, 10, 11, 12, 13, 14 4074 1VP34 1/2 105477 AK46 3/4 101291 1 A33 11.56
1/2 AL21
AK1 (115/1); AK2 (208/1); AK3 (230/1);
AK5 (208/3); AK6 (230/3); AK7 (460/3);
AK8 (575/3)
AM 5, 6, 7, 8 13580 1VL34 5/8 19108 AK64 3/4 105490 1 A36 12.57
AM 9, 10, 11 105476 1VL44 5/8 105484 AK71H A 3/4 105493 1 A39 12.32
AM 12, 13, 14, 15, 16, 17, 18 13580 1VL34 5/8 105478 AK41 3/4 101291 A33 12.46
3/4 AL22
AM 7, 8, 9, 10 7962 1VL40 5/8 19108 AK64 3/4 16018 1 A38 12.7
AM 11, 12, 13, 14, 15 13580 1VL34 5/8 105477 AK46 3/4 105488 1 A34 12.56
AM 16, 17, 18, 19, 20, 21, 22 7962 1VL40 5/8 105478 AK41 3/4 105488 1 A34 12.58
1 AL23
AM 9, 10, 11, 12, 13, 14, 15 13580 1VL34 5/8 105477 AK46 3/4 105488 1 A34 12.56
AM 16, 17, 18, 19, 20, 21, 22 7962 1VL40 5/8 105478 AK41 3/4 105488 1 A34 12.50
1-1/2 AL24
AK1 (115/1); AK2 (208/1); AK3 (230/1);
AK5 (208/3); AK6 (230/3); AK7 (460/3)
AM 11, 12, 13 105476 1VL44 5/8 19108 AK64 3/4 16018 1 A38 12.40
AM 14, 15, 16, 17 7962 1VL40 5/8 105479 AK49 3/4 105489 1 A35 12.43
AM 18, 19, 20, 21, 22 7962 1VL40 5/8 105478 AK41 3/4 105488 1 A34 12.58
AK8 (575/3)
AM 11, 12, 13 106758 1VL44 7/8 19108 AK64 3/4 16018 1 A38 12.40
AM 14, 15, 16, 17 106748 1VL40 7/8 105479 AK49 3/4 105489 1 A35 12.43
AM 18, 19, 20, 21, 22 106748 1VL40 7/8 105478 AK41 3/4 105488 1 A34 12.58
2 AL25
AK3 (230/1); AK5 (208/3); AK6 (230/3);
AK7 (460/3); AK8 (575/3)
AM 13, 14, 15, 16, 17 106748 1VL40 7/8 105479 AK49 3/4 105489 1 A35 12.43
AM 18, 19, 20, 21, 22 106748 1VL40 7/8 105478 AK41 3/4 105488 1 A34 12.58
3 AL26
AK5 (208/3); AK6 (230/3); AK7 (460/3);
AK8 (575/3)
AM 13, 14, 15, 16 ,17 37451 1VM50 7/8 111606 BK140 3/4 92221 1 B52 12.46
AM 18, 19, 20, 21, 22, 23, 24 37451 1VM50 7/8 111607 AK74 3/4 105493 1 A39 12.27
150
175
200
225
1/3 AL20
AK1 (115/1); AK2 (208/1); AK3 (230/1);
AK5 (208/3); AK6 (230/3); AK7 (460/3)
AM 2, 3, 4 4074 1VL34 1/2 19111 AK84 1 50470 1 A43 13.86
AM 5, 6, 7 4074 1VL34 1/2 18797 AK64 1 16019 1 A40 14.08
1/2 AL21
AK1 (115/1); AK2 (208/1); AK3 (230/1);
AK5 (208/3); AK6 (230/3); AK7 (460/3);
AK8 (575/3)
AM 2, 3, 4 13580 1VL34 5/8 19111 AK84 1 50470 1 A43 14.00
AM 5, 6, 7, 8 13580 1VL34 5/8 18797 AK64 1 16019 1 A40 14.08
AM 9, 10, 11 13580 1VL34 5/8 105481 AK46 1 105491 1 A37 14.06
3/4 AL22
AM 5, 6, 7, 8 13580 1VL34 5/8 18797 AK64 1 16019 1 A40 14.58
AM 9, 10, 11, 12, 13, 14, 15 13580 1VL34 5/8 105481 AK46 1 105488 1 A34 14.56
1 AL23
AM 7, 8 13580 1VL34 5/8 18797 AK64 1 16019 1 A40 14.08
AM 9, 10, 11, 12, 13, 14 13580 1VL34 5/8 105481 AK46 1 105491 1 A34 14.06
AM 15, 16, 17 7962 1VL40 5/8 105481 AK46 1 16018 1 A38 14.18
1-1/2 AL24
AK1 (115/1); AK2 (208/1); AK3 (230/1);
AK5 (208/3); AK6 (230/3); AK7 (460/3)
AM 9, 10, 11 105476 1VL44 5/8 105484 AK71H A 1 101412 1 A42 13.83
AM 12, 13, 14, 15, 16 105476 1VL44 5/8 105482 AK56 1 16019 1 A40 14.07
AM 17, 18 7962 1VL40 5/8 105481 AK46 1 16018 1 A38 14.18
AK8 (575/3)
AM 9, 10, 11 106758 1VL44 7/8 105484 AK71H A 1 101412 1 A42 13.83
AM 12, 13, 14, 15, 16 106748 1VL40 7/8 105482 AK56 1 16019 1 A40 14.07
AM 17, 18 106748 1VL40 7/8 105481 AK46 1 16018 1 A38 14.18
2 AL25
AK5 (208/3); AK6 (230/3);
AK7 (460/3); AK8 (575/3)
AM 9, 10, 11 106748 1VL40 7/8 18797 AK64 1 50500 1 A41 14.21
AM 12, 13, 14, 15, 16, 17 106758 1VL44 7/8 105482 AK56 1 16019 1 A40 14.07
AM 18, 19, 20 106748 1VL40 7/8 105481 AK46 1 16018 1 A38 14.18
3 AL26
AM 13, 14, 15, 16, 17 106748 1VL40 7/8 111609 AK99 1 50474 1 A47 14.20
AM 18, 19, 20, 21 106748 1VL40 7/8 19111 AK84 1 52966 1 A44 14.00
250
300
1/2 AL21 AK1 (115/1); AK2 (208/1); AK3 (230/1);
AK5 (208/3); AK6 (230/3); AK7 (460/3);
AK8 (575/3)
AM 2, 3, 4 13580 1VL34 5/8 19111 AK84 1 105493 1 A39 11.82
AM 5, 6, 7, 8 13580 1VL34 5/8 18797 AK64 1 105490 1 A36 12.06
3/4 AL22
AM 5, 6, 7 13580 1VL34 5/8 18797 AK64 1 105490 1 A36 12.06
AM 8, 9, 10, 11 13580 1VL34 5/8 105482 AK56 1 105489 1 A35 12.24
1 AL23
AK1 (115/1); AK2 (208/1); AK3 (230/1); AK5
(208/3); AK6 (230/3); AK7 (460/3); AK8 (575/3)
AM 7, 8, 9, 10, 11 13580 1VL34 5/8 105482 AK56 1 105489 1 A35 12.24
AM 12, 13, 14, 15, 16 13580 1VL34 5/8 105481 AK46 1 101291 1 A33 12.06
1-1/2 AL24
AK1 (115/1); AK2 (208/1); AK3 (230/1);
AK5 (208/3); AK6 (230/3); AK7 (460/3)
AM 9, 10, 11 7962 1VL40 5/8 18797 AK64 1 105491 1 A37 12.2
AM 12, 13, 14, 15, 16 105476 1VL44 5/8 105482 AK56 1 105491 1 A37 12.06
AM 17, 18, 19, 20, 21, 22, 23 105476 1VL44 5/8 105481 AK46 1 105489 1 A35 12.37
AK8 (575/3)
AM 9, 10, 11 106748 1VL40 7/8 18797 AK64 1 105491 1 A37 12.20
AM 12, 13, 14, 15, 16 106758 1VL44 7/8 105482 AK56 1 105491 1 A37 12.06
AM 17, 18, 19, 20, 21, 22, 23 106758 1VL44 7/8 105481 AK46 1 105489 1 A35 12.37
2 AL25
AK5 (208/3); AK6 (230/3); AK7 (460/3);
AK8 (575/3)
AM 9, 10, 11 106748 1VL40 7/8 18797 AK64 1 105491 1 A37
AM 12, 13, 14, 15, 16 106758 1VL44 7/8 105482 AK56 1 105490 1 A36
AM 17, 18, 19, 20, 21, 22, 23 106758 1VL44 7/8 105481 AK46 1 105489 1 A35
3 AL26
AM 13, 14, 15, 16, 17 106748 1VL40 7/8 111609 AK99 1 50470 1 A43 12.14
AM 18, 19, 20, 21, 22 37451 1VM50 7/8 16153 AK104 1 50472 1 A45 12.02
350
400
3/4 AL22
AK1 (115/1); AK2 (208/1); AK3 (230/1);
AK5 (208/3); AK6 (230/3); AK7 (460/3)
AM 2, 3, 4 13580 1VL34 5/8 19111 AK84 1 52966 1 A44 14.37
AM 5, 6 7962 1VL40 5/8 19111 AK84 1 52966 1 A44 14.01
1 AL23
AK1 (115/1); AK2 (208/1); AK3 (230/1);
AK5 (208/3); AK6 (230/3); AK7 (460/3)
AM 3, 4, 5, 6 13580 1VL34 5/8 105484 AK71H C 1 50500 1 A41 13.98
AM 7, 8, 9, 10, 11 13580 1VL34 5/8 105482 AK56 1 105493 1 A39 14.25
Drive Components - Model SCE Series 6 w/Totally Enclosed (TEFC) Motor (See drive information, page 17)
Drive
Components
- Model Series
SCE Series
6 with Open
Motor (cont'd)
Unit
Sizes
Motor
Voltage Option
Drive AM Nos. Motor Pulley Blower Pulley Belt *Shaft
Centerline HP Opt (See Key, chart on page 17.) P/N Mfr # Bore P/N Mfr # Bore P/N Qty Mfr #
350
400
1-1/2 AL7
AK1 (115/1); AK2
(208/1); AK3 (230/1);
AK5 (208/3); AK6
(230/3); AK7 (460/3)
AM 6, 7, 8, 9 7962 1VL40 5/8 105484 AK71H C 1 101412 1 A42 14.12
AM 10, 11, 12, 13 105476 1VL44 5/8 18797 AK64 1 101412 1 A42 13.91
AM 14, 15, 16, 17, 18 7962 1VL40 5/8 105481 AK46 1 16048 1 A38 14.18
2 AL8
AK5 (208/3); AK6
(230/3); AK7 (460/3);
AK8 (575/3)
AM 9, 10, 11 7962 1VL40 5/8 18797 AK64 1 50500 1 A41 14.21
AM 12, 13, 14, 15, 16 105476 1VL44 5/8 105482 AK56 1 16019 1 A40 14.07
AM 17, 18, 19 20 7962 1VL40 5/8 105481 AK46 1 16018 1 A38 14.18
3 AL9
AM 9, 10, 11, 12 7962 1VL40 5/8 202652 AK124 1 50513 1 A52 12.14
AM 13, 14, 15, 16, 17, 18, 19 7962 1VL40 5/8 202653 AK94 1 50474 1 A47 12.14
AM 20, 21, 22, 23, 24, 25, 26 7962 1VL40 5/8 105483 AK69 1 50470 1 A43 12.02
5 AL10
AM 12, 13, 14, 15, 16, 17 6599 2VP42 7/8 7955 2AK104 1 65403 1 A48 14.11
AM 18, 19, 20, 21, 22 8973 2VP50 7/8 7955 2AK104 1 50472 1 A49 14.06
