Form P-SC, P/N 269822R3, Page 17
Replacement Holding Coils for IEC Starters
Drive Options and Components
Drive components include the belt, motor pulley, blower pulley, and
bushings, if required. The table at the right identifies the RPM range of
the drive option. Drive options are listed by AM No. (NOTE: Components
may have changed. If shaft size is different than listed or if there are
no parts listed, check the replacement parts tag and/or contact the
distributor or factory service for replacement parts.)
Belt Tension - Check belt tension. Proper belt tension is important to the
OPT RPM
Range
OPT RPM
Range
OPT
RPM
Range
OPT
RPM
Range
AM2 451-500 AM8 751-800 AM14 1051-1100 AM19 1301-1350
AM3 501-550 AM9 801-850 AM15 1101-1150 AM20 1351-1400
AM4 551-600 AM10 851-900 AM16 1151-1200 AM21 1401-1450
AM5 601-650 AM11 901-950 AM17 1201-1250 AM22 1451-1500
AM6 651-700 AM12 951-1000 AM18 1251-1300 AM23 1501-1550
AM7 701-750 AM13 1001-1050
long life of the belt and motor. A loose belt will cause wear and slippage. Too much tension will cause excessive motor and blower bearing wear. If
adjustment is required, adjust belt tension with the adjusting screw on the motor base until the belt can be depressed 1/2" to 3/4". Tighten the lock
nut on the adjusting screw. Be sure the belt is aligned in the pulleys .
Unit
Sizes
Motor
Voltage Option
Drive AM Nos. Motor Pulley Blower Pulley Belt *Shaft
Centerline HP Opt (See Key, chart above) P/N Mfr # Bore P/N Mfr # Bore P/N Qty Mfr #
125
1/4 AL2
AK1 (115/1);
AK2 (208/1);
AK3 (230/1);
AK5 (208/3);
AK6 (230/3);
AK7 (460/3)
AM 1, 2, 3, 4 4074 1VL34 1/2 19110 AK84 3/4 105493 1 A39 11.82
AM 5, 6, 7, 8, 9 13491 1VL40 1/2 111607 AK74 3/4 16018 1 A38 12.06
1/3 AL3
AM 2, 3, 4 4074 1VP34 1/2 19110 AK84 3/4 105493 1 A39 11.56
AM 5, 6, 7 13491 1VL40 1/2 111607 AK74 3/4 16018 1 A38 11.82
AM 9, 10, 11, 12, 13, 14 4074 1VP34 1/2 105477 AK46 3/4 101291 1 A33 11.56
1/2 AL4
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
AM 5, 6, 7, 8 13580 1VL34 5/8 19108 AK64 3/4 105490 1 A36 12.57
AM 9, 10, 11 105476 1VL44 5/8 105484 AK71H A 3/4 105493 1 A39 12.32
AM 12, 13, 14, 15, 16, 17, 18 13580 1VL34 5/8 105478 AK41 3/4 101291 A33 12.46
3/4 AL5
AM 7, 8, 9, 10 7962 1VL40 5/8 19108 AK64 3/4 16018 1 A38 12.70
AM 11, 12, 13, 14, 15 13580 1VL34 5/8 105477 AK46 3/4 105488 1 A34 12.56
AM 16, 17, 18, 19, 20, 21, 22 7962 1VL40 5/8 105478 AK41 3/4 105488 1 A34 12.58
1 AL6
AM 9, 10, 11, 12, 13, 14, 15 13580 1VL34 5/8 105477 AK46 3/4 105488 1 A34 12.56
AM 16, 17, 18, 19, 20, 21, 22 7962 1VL40 5/8 105478 AK41 3/4 105488 1 A34 12.50
1-1/2 AL7
AM 11,12, 13 105476 1VL44 5/8 19108 AK64 3/4 16018 1 A38 12.40
AM 14, 15, 16, 17 7962 1VL40 5/8 105479 AK49 3/4 105489 1 A35 12.43
AM 18, 19, 20, 21, 22 7962 1VL40 5/8 105478 AK41 3/4 105488 1 A34 12.58
2 AL8
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
AM 13, 14,15,16,17 7962 1VL40 5/8 105479 AK49 3/4 105489 1 A35 12.43
AM 18, 19, 20, 21, 22 7962 1VL40 5/8 105478 AK41 3/4 105488 1 A34 12.58
3 AL9
AM 13, 14, 15, 16, 17 13013 1VM50 5/8 111606 BK140 3/4 92221 1 B52 12.46
AM 18, 19, 20, 21, 22, 23, 24 13013 1VM50 5/8 111607 AK74 3/4 105493 1 A39 12.27
150
175
200
225
1/2 AL4
AK1 (115/1);
AK2 (208/1);
AK3 (230/1);
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
AM 2, 3, 4 13580 1VL34 5/8 19111 AK84 1 50470 1 A43 14.00
AM 5, 6, 7, 8 13580 1VL34 5/8 18797 AK64 1 16019 1 A40 14.08
AM 9, 10, 11 13580 1VL34 5/8 105481 AK46 1 105491 1 A37 14.06
3/4 AL5
AM 5, 6, 7, 8 13580 1VL34 5/8 18797 AK64 1 16019 1 A40 14.58
AM 9, 10, 11, 12, 13, 14, 15 13580 1VL34 5/8 105481 AK46 1 105491 1 A37 14.56
1 AL6
AM 7, 8 13580 1VL34 5/8 18797 AK64 1 16019 1 A40 14.08
AM 9, 10, 11, 12, 13, 14 13580 1VL34 5/8 105481 AK46 1 105491 1 A37 14.06
AM 15, 16, 17 7962 1VL40 5/8 105481 AK46 1 16018 1 A38 14.18
1-1/2 AL7
AM 9, 10, 11 105476 1VL44 5/8 19108 AK64 1 101412 1 A42 13.83
AM 12, 13, 14, 15, 16 105476 1VL44 5/8 105484 AK71H C 1 16019 1 A40 14.07
AM 17, 18 7962 1VL40 5/8 105482 AK56 1 16018 1 A38 14.18
2 AL8
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
AM 9, 10, 11 7962 1VL40 5/8 18797 AK64 1 50500 1 A41 17.21
AM 12, 13, 14, 15, 16, 17 105476 1VL44 5/8 105482 AK56 1 16019 1 A40 14.07
AM 18, 19, 20 7962 1VL40 5/8 105481 AK46 1 16018 1 A38 14.18
3 AL9
AM 13, 14, 15, 16, 17 13013 1VM50 5/8 111606 BK140 1 50474 1 A47 14.20
AM 18, 19, 20, 21 13013 1VM50 5/8 111607 AK74 1 52966 1 A44 14.00
5 AL10
AM 16, 17, 18, 19, 20, 21, 22 87500 2VP36 7/8 91633 2TB86 D 1 16139 1 B45 14.31
AM 20, 21, 22, 23 8973 2VP50 7/8 7955 2BK100 1 50477 1 A49 14.07
250
300
1/2 AL4
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
AM 2, 3, 4 13580 1VL34 5/8 19111 AK84 1 105493 1 A39 11.82
AM 5, 6, 7, 8 13580 1VL34 5/8 18797 AK64 1 105490 1 A36 12.06
3/4 AL5
AM 5, 6, 7 13580 1VL34 5/8 18797 AK64 1 105490 1 A36 12.06
AM 8, 9, 10, 11 13580 1VL34 5/8 105482 AK56 1 105489 1 A35 12.24
1 AL6
AM 7, 8, 9, 10, 11 13580 1VL34 5/8 105482 AK56 1 105489 1 A35 12.24
AM 12, 13, 14, 15, 16 13580 1VL34 5/8 105481 AK46 1 101291 1 A33 12.06
250
300
1-1/2 AL7
AAK1 (115/1); AK2
(208/1); AK3 (230/1);
AK5 (208/3); AK6
(230/3); AK7 (460/3);
AK8 (575/3)
AM 9, 10, 11 7962 1VL40 5/8 18797 AK64 1 105491 1 A37 12.2
AM 12, 13, 14, 15, 16 105476 1VL44 5/8 105482 AK56 1 105491 1 A36 12.06
AM 17, 18, 19, 20, 21, 22, 23 105476 1VL44 5/8 105481 AK46 1 105489 1 A35 12.37
2 AL8
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
AM 9, 10, 11 7962 1VL40 5/8 18797 AK64 1 105491 1 A37 12.20
AM 12, 13, 14, 15, 16 105476 1VL44 5/8 105482 AK56 1 105490 1 A36 12.06
AM 17, 18, 19, 20, 21, 22, 23 105476 1VL44 5/8 105481 AK46 1 105489 1 A35 12.37
3 AL9
AM 9, 10, 11, 12 7962 IVL40 5/8 202652 AK124 1 50475 1 A49 12.14
AM 13, 14, 15, 16, 17 7962 IVL40 5/8 202653 AK94 1 52966 1 A44 12.14
AM 18, 19, 20, 21, 22 7962 IVL40 5/8 105483 AK89 1 16019 1 A40 12.02
5 AL10
AM 15, 16, 17, 18, 19 87500 2VP36 7/8 91633 2TB86 D 1 111738 1 B41 12.27
AM 20, 21, 22, 23 8973 2VP50 7/8 7955 2AK104 1 50472 1 A45 12.02
350
400
3/4 AL5
AK1 (115/1); AK2
(208/1); AK3 (230/1);
AK5 (208/3); AK6
(230/3); AK7 (460/3)
AM 2, 3, 4 13580 1VL34 5/8 19111 AK84 1 52966 1 A44 14.37
AM 5, 6 7962 1VL40 5/8 19111 AK84 1 52966 1 A44 14.01
1 AL6
AM 3, 4, 5, 6 13580 1VL34 5/8 105484 AK71H C 1 50500 1 A41 13.98
AM 7, 8, 9, 10, 11 13580 1VL34 5/8 105482 AK56 1 105493 1 A39 14.25
Drives -
Model Series
SCE Series
6 with Open
Motor
Voltage GE # Reznor
P/N
For Use with Starters
Beginning with GE#
24 LB1A-C 151280 CL00; CL01; CL02; CL25
120 LB1A-J 151281 CL00; CL01; CL02; CL25
208 LB1A-L 151282 CL00; CL01; CL02; CL25
230 LB1A-S 151283 CL00; CL01; CL02; CL25
460 LB1A-U 151284 CL00; CL01; CL02; CL25
Voltage GE # Reznor
P/N
For Use with Starters
Beginning with GE#
575 LB1A-Y 151285 CL00; CL01; CL02; CL25
24 LB3A-C 151286 CL04; CL45
120 LB3A-J 151287 CL04; CL45
208 LB3A-L 151288 CL04; CL45
230 LB3A-S 151289 CL04; CL45
Voltage GE #
Reznor
P/N
For Use with Starters
Beginning with GE#
460 LB3A-U 151290 CL04; CL45
575 LB3A-Y 151291 CL04; CL45
208 LB4A-L 151292 CL06; CL07; CL08; CL09
230 LB4A-S 151293 CL06; CL07; CL08; CL09
460 LB4A-U 151294 CL06; CL07; CL08; CL09
*Distance between
blower shaft and motor
centerline with belts
tensioned properly.
**Not for Model 200
or 225.
A Use a 3/4 "H" blower
pulley bushing, P/N
105487;
C Use a 1" blower
pulley bushing, P/N
92203;
D Use a 1" Q1 motor
pulley bushing, P/N
6605.
