Reznor SSCDBL Parts Manuals - Manual (Page 21)

Form P-SC, P/N 269822R3, Page 21
Drive
Components
for Premium
Efficiency
Motors
(See drive
information,
top of page
17.)
Unit
Sizes
Motor Voltage
Option
Drive AM Nos. Motor Pulley Blower Pulley Belt *Shaft
Centerline HP Opt (See Key, chart on page 17.) P/N Mfr # Bore P/N Mfr # Bore P/N Qty Mfr #
All
"BL"
Units
1 AL36
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
AM 2, 3, 4 110125 1VP34 7/8 111862 AK84 1-3/16 16134 1 A57 20.94
AM 5, 6, 7 110125 1VP34 7/8 105484 AK71H A 1-3/16 16132 1 A55 21.03
1-1/2 AL37
AM 3, 4, 5, 6, 7 110125 1VP34 7/8 105484 AK71H A 1-3/16 16132 1 A55 21.03
AM 8, 9, 10, 11 106758 1VL44 7/8 106256 AK74 1-3/16 16134 1 A57 21.11
2 AL38
AM 3, 4, 5, 6, 7 110125 1VP34 7/8 105484 AK71H A 1-3/16 16132 1 A55 20.03
AM 8, 9, 10, 11 106758 1VL44 7/8 105484 AK71H A 1-3/16 16133 1 A56 20.85
AM 12, 13, 14, 15, 16 106758 1VL44 7/8 110807 AK56H A 1-3/16 16131 1 A54 21.07
3 AL39
AM 7, 8, 9 37451 1VM50 7/8 16160 AK184 1-3/16 92264 1 A78 20.95
AM 10, 11, 12, 13 106758 1VL44 7/8 16158 AK134 1-3/16 16558 1 A69 20.96
AM 14, 15, 16, 17, 18 37451 1VM50 7/8 16156 AK124 1-3/16 111870 1 A66 20.92
5 AL40
AM 8, 9, 10, 11 7963 2VP42 1-1/8 16161 2AK134 1-3/16 16139 1 A67 21.08
AM 12, 13, 14, 15 105581 2VP50 1-1/8 16161 2AK34 1-3/16 92408 1 A68 21.01
AM 16, 17, 18, 19, 20 7963 2VP42 1-1/8 16003 2BK100 1-3/16 50477 1 A60 21.08
7-1/2 AL41
AM 10, 11 16150 2VP62 1-3/8 16168 2BK110 1-3/16 92414 1 B64 20.47
AM 12, 13 16150 2VP62 1-3/8 16003 2BK100 1-3/16 7950 1 B62 20.31
AM 14, 15, 16 16150 2VP62 1-3/8 91633 2TB86 B 1-3/16 92280 1 BX59 20.47
AM 17, 18, 19, 20 110771 2VP65 1-3/8 89648 2BK80H A 1-3/16 92280 1 BX59 20.37
10 AL42
AM 10, 11 16150 2VP62 1-3/8 16168 2BK110 1-3/16 92414 1 B64 20.47
AM 12, 13 16150 2VP62 1-3/8 16003 2BK100 1-3/16 7950 1 B62 20.31
AM 14, 15, 16 16150 2VP62 1-3/8 91633 2TB86 B 1-3/16 92280 1 BX59 20.47
AM 17, 18, 19, 20 110771 2VP65 1-3/8 89648 2BK80H A 1-3/16 92280 1 BX59 20.37
**15
& 20
AL43 **AM 15, 16, 17 148593 2MVP70B84P D 1-5/8 113811 2BK120H C 1-7/16 80841 3 BX67 20.47
AL44
**AM 18, 19, 20, 21 148594 2MVP80B94Q E 1-5/8 114045 2B5V110 F 1-7/16 148605 3 BX69 20.53
**AM 22, 23, 24 148593 2MVP70B84P D 1-5/8 148597 2B5V90 F 1-7/16 114258 3 BX64 20.11
***15 AL43
***AM 15, 16, 17 148593 2MVP70B84P D 1-5/8 113811 2BK120H C 1-7/16 80841 2 BX67
***AM 18, 19, 20, 21 148594 2MVP80B94Q E 1-5/8 114045 2B5V110 F 1-7/16 148605 2 BX69
***AM 22, 23, 24 148593 2MVP70B84P D 1-5/8 148597 2B5V90 F 1-7/16 114258 2 BX64
***20 AL44
***AM17 148593 2MVP70B84P D 1-5/8 113811 2BK120H C 1-7/16 80841 2 BX67
***AM 18, 19, 20, 21 148594 2MVP80B94Q E 1-5/8 114045 2B5V110 F 1-7/16 148605 2 BX69
***AM 22, 23, 24 148593 2MVP70B84P D 1-5/8 148597 2B5V90 F 1-7/16 114258 2 BX64
*Distance between blower shaft and motor centerline with belts tensioned properly. ** Three-Groove Drives ***Two-Groove Drives
Unit
Sizes
Motor
Voltage Option
Drive AM Nos. Motor Pulley Blower Pulley Belt *Shaft
Centerline HP Opt (See Key, chart on page 17.) P/N Mfr # Bore P/N Mfr # Bore P/N Qty Mfr #
All
"BL"
Units
7-1/2 AL32
AK3 (230/1); AK5 (208/3); AK6 (230/3);
AK7 (460/3); AK8 (575/3)
AM 10, 11 16150 2VP62 1-3/8 16138 2BK110 1-3/16 92414 1 B64 20.47
AM 12, 13 16150 2VP62 1-3/8 16003 2BK100 1-3/16 7950 1 B62 20.31
AM 14, 15, 16 16150 2VP62 1-3/8 91633 2TB86 A 1-3/16 92280 1 BX59 20.47
AM 17, 18, 19, 20 110771 2VP65 1-3/8 89648 2BK80H C 1-3-16 92280 1 BX59 20.37
10 AL33
AM 10, 11 16150 2VP62 1-3/8 16168 2BK110 1-3/16 92414 1 B64 20.47
AM 12, 13 16150 2VP62 1-3/8 16003 2BK100 1-3/16 7950 1 B62 20.31
AM 14, 15, 16 16150 2VP62 1-3/8 91633 2TB86 A 1-3/16 92280 1 BX59 20.47
AM 17, 18, 19, 20 110771 2VP65 1-3/8 89648 2BK80H C 1-3/16 92280 1 BX59 20.37
**15
& 20
AL34
AK5 (208/3); AK6 (230/3); AK7 (460/3);
AK8 (575/3)
**AM 15, 16, 17 148593 2MVP70B84P E 1-5/8 113811 2BK120H D 1-7/16 80841 3 BX67 20.47
AL35
**AM 18, 19, 20, 21 148594 2MVP80B94Q F 1-5/8 114045 2B5V110 G 1-7/16 148605 3 BX69 20.53
**AM 22, 23, 24 148593 2MVP70B84P E 1-5/8 148597 2B5V90 G 1-7/16 114258 3 BX64 20.11
***15 AL34
***AM 15, 16, 17 148593 E 2MVP70B84P 1-5/8 113811 2BK120H D 1-7/16 80841 2 BX67 20.47
***AM 18, 19, 20, 21 148594 F 2MVP80B94Q 1-5/8 114045 2B5V110 G 1-7/16 148605 2 BX69 20.53
***AM 22, 23, 24 148593 E 2MVP70B84P 1-5/8 148597 2B5V90 G 1-7/16 114258 2 BX64 20.11
***20 AL35
***AM17 148593 E 2MVP70B84P 1-5/8 113811 2BK120H D 1-7/16 80841 2 BX67 20.47
***AM 18, 19, 20, 21 148594 F 2MVP80B94Q 1-5/8 114045 2B5V110 G 1-7/16 148605 2 BX69 20.53
***AM 22, 23, 24 148593 E 2MVP70B84P 1-5/8 148597 2B5V90 G 1-7/16 114258 2 BX64 20.11
*Distance between blower shaft and motor centerline with belts tensioned properly. ** Three-Groove Drives ***Two-Groove Drives
A Use 1-3/16 "H" Blower Pulley Bushing, P/N 106260 D Use 1-7/16 "B" Blower Pulley Bushing, P/N 114033 G Use 1-7/16 "P1" Blower Pulley Bushing, P/N 106261
B Use 1-3/16 "Q1" Blower Pulley Bushing, P/N 39460 E Use 1-5/8 "P2" Motor Pulley Bushing, P/N 148595
C Use 1-7/16 "H" Blower Pulley Bushing, P/N 89659 F Use 1-5/8 "Q2" Motor Pulley Bushing, P/N 148596
Drive
Components
for Two-
Speed Motors
(See drive
information, top
of page 17.)
Unit
Sizes
Motor Voltage
Option
Drive AM Nos. Motor Pulley Blower Pulley Belt *Shaft
Centerline HP Opt (See Key, chart on page 17.) P/N Mfr # Bore P/N Mfr # Bore P/N Qty Mfr #
All
"BL"
Units
1 AL45
AK5 (208/3);
AK6 (230/3);
AK7 (460/3)
AM 2, 3, 4 110125 1VP34 7/8 111862 AK84 1-3/16 16134 1 A57 20.94
AM 5, 6, 7 110125 1VP34 7/8 105484 AK71H A 1-3/16 16132 1 A55 21.03
1-1/2 AL46
AM 3, 4, 5, 6, 7 110125 1VP34 7/8 105484 AK71H A 1-3/16 16132 1 A55 21.03
AM 8, 9, 10, 11 106758 1VL44 7/8 106256 AK74 1-3/16 16134 1 A57 21.11
2 AL47
AM 4, 5 111681 1VP50 1-1/8 16156 AK124 1-3/16 111870 1 A66 20.92
AM 6, 7, 8, 9 110151 1VP44 1-1/8 111862 AK84 1-3/16 92402 1 A59 21.28
AM 10, 11, 12, 13 110151 1VP44 1-1/8 112026 BK85H A 1-3/16 92225 1 B57 21.22
AM 14, 15, 16, 17, 18, 19 110151 1VP44 1-1/8 112035 BK60 1-3/16 92239 1 BX54 20.93
3 AL48
AM 4, 5 111681 1VP50 1-1/8 16156 AK124 1-3/16 111870 1 A66 20.92
AM 6, 7, 8, 9 110151 1VP44 1-1/8 111862 AK84 1-3/16 92402 1 A59 21.28
AM 10, 11, 12, 13 110151 1VP44 1-1/8 112026 BK75H A 1-3/16 92225 1 B57 21.22
AM 14, 15, 16, 17, 18, 19 110151 1VP44 1-1/8 112035 BK60 1-3/16 92239 1 BX54 20.93
5 AL49
AM 8, 9, 10, 11 106257 2VP60 1-3/8 16168 2BK110 1-3/16 6010 1 B65 21.28
AM 12, 13, 14, 15 106257 2VP60 1-3/8 16167 2BK90 1-3/16 92289 1 BX61 20.93
AM 16, 17, 18, 19, 20 106257 2VP60 1-3/8 92419 2TB70 B 1-3/16 16143 1 B59 21.07
7-1/2 AL50
AM 10, 11 16150 2VP62 1-3/8 16168 2BK110 1-3/16 92414 1 B64 20.47
AM 12, 13 16150 2VP62 1-3/8 16003 2BK100 1-3/16 7950 1 B62 20.31
AM 14, 15, 16 16150 2VP62 1-3/8 91633 2TB86 B 1-3/16 92280 1 BX59 20.47
AM 17, 18, 19, 20 110771 2VP65 1-3/8 89648 2BK80H A 1-3/16 92280 1 BX59 20.37
10 AL51
AM 13, 14, 15, 16 91615 2MPV40-B54 1-5/8 89648 2BK80H A 1-3/16 92226 1 B58 20.47
AM 17, 18, 19, 20, 21, 22 91615 2MPV40-B54 1-5/8 110810 2BK70H A 1-3/16 92225 1 B57 20.37
*Distance between blower shaft and motor centerline with belts tensioned properly. ** Three-Groove Drives ***Two-Groove Drives
A Use 1-3/16 "H" Blower Pulley Bushing, P/N 106260 B Use 1-3/16 "Q1" Blower Pulley Bushing, P/N 39460
A Use 1-3/16 "H" Blower Pulley Bushing, P/N 106260; B Use 1-3/16 "Q1" Blower Pulley Bushing, P/N 39460; C Use 1-7/16 "H" Blower Pulley Bushing, P/N 89659; D Use 1-7/16 "B" Blower Pulley
Bushing, P/N 114033; E Use 1-5/8 "P2" Motor Pulley Bushing, P/N 148595; F Use 1-5/8 "Q2" Motor Pulley Bushing, P/N 148596; G Use 1-7/16 "P1" Blower Pulley Bushing, P/N 106261;
