Form P-SC, P/N 269822R3, Page 16
TEFC Motor (cont'd) Frame
Size
Service
Factor
Power
Factor
Starter (AN10) Starter Overload
Type HP AL Mfr's #. P/N fla volt ph Mfr # P/N Mfr # min max P/N
TEFC
15 34
E301M 142443 38.0 240 3 254T 1.15 82 CL06A311M-S 151172 RTA2-E 30.00 43.00 151206
E301M 142443 19.0 480 3 254T 1.15 82 CL25A310T-U 151162 RTA1-T 17.50 22.00 151197
FM2333-5 142444 15.0 575 3 254T 1.15 82 CL02A310T-Y 151158 RTA1-P 10.00 16.00 151194
20 35
FM2334T 142301 52.0 240 3 256T 1.15 81 CL07A311M-S 151175 RTA2-G 42.00 55.00 151202
FM2334T 142301 26.0 480 3 256T 1.15 81 CL04A310M-U 151167 RTA1-V 25.00 32.00 151199
FM2334T-5 142302 20.6 575 3 256T 1.15 81 CL25A310T-Y 151163 RTA1-T 17.50 22.00 151197
Premium Efficient Motor Frame
Size
Service
Factor
Power
Factor
Starter (AN10) Starter Overload
Type HP AL Mfr's #. P/N fla volt ph Mfr # P/N Mfr # min max P/N
EE 1 36
DHP0014 159328 3.1 208 3 143T 1.15 83.5 CL00A310T-L 151150 RTA1-K 2.50 4.10 151190
DHP0014 159328 2.8 240 3 143T 1.15 CL00A310T-S 151147 RTA1-K 2.50 4.10 151190
DHP0014 159328 1.4 480 3 143T 1.15 CL00A310T-U 151148 RTA1-G 1.00 1.50 151187
E1006 158175 1.1 575 3 N143T 1.15 CL00A310T-Y 151149 RTA1-G 1.00 1.50 151187
EE 1.5 37
E104 105662 4.5 208 3 P145T 1.15 86 CL00A310T-L 151150 RTA1-L 4.00 6.30 151191
E1016 159329 4.0 240 3 145T 1.15 CL00A310T-S 151147 RTA1-K 2.50 4.10 151190
E1016 159329 2.0 480 3 145T 1.15 CL00A310T-U 151148 RTA1-J 1.90 2.70 151189
E1007 158162 1.6 575 3 R145T 1.15 85.3 CL00A310T-Y 151149 RTA1-H 1.30 1.90 151188
EE 2 38
E105 105664 6.1 208 3 P145T 1.15 86.8 CL00A310T-L 151150 RTA1-L 4.00 6.30 151191
E1017 159027 5.6 240 3 145T 1.15 CL00A310T-S 151147 RTA1-L 4.00 6.30 151191
E1017 159027 2.8 480 3 145T 1.15 CL00A310T-U 151148 RTA1-K 2.50 4.10 151190
E1008 158176 2.1 575 3 P145T 1.15 86 CL00A310T-Y 151149 RTA1-J 1.90 2.70 151189
EE 3 39
35L405S489G3 159186 8.3 208 3 145T 1.15 CL00A310T-L 151150 RTA1-N 8.00 12.00 151193
EM3158T 159028 7.4 240 3 145T CL00A310T-S 151147 RTA1-M 5.50 8.50 151192
EM3158T 159028 3.7 480 3 145T CL00A310T-U 151148 RTA1-K 2.50 4.10 151190
35L405S709G1 159030 3.0 575 3 145T 1.15 CL00A310T-Y 151149 RTA1-K 2.50 4.10 151190
EE 5 40
E204 159029 11.6 208 3 H182T 1.15 89 CL02A310T-L 151159 RTA1-P 10.00 16.00 151194
E204 159029 11.6 240 3 H182T 1.15 89 CL02A310T-S 151157 RTA1-P 10.00 16.00 151194
E204 159029 5.8 480 3 H182T 1.15 89 CL00A310T-U 151148 RTA1-M 5.50 8.50 151192
M3613T-5 111602 4.8 575 3 184T 1.15 CL00A310T-Y 151149 RTA1-L 4.00 6.30 151191
EE 7.5 41
E316 159331 21.4 208 3 D213T 1.15 82 CL04A310M-L 151169 RTA1-U 21.00 26.00 151198
E317 159332 18.6 240 3 D213T 1.15 82 CL25A310T-S 151161 RTA1-T 17.50 22.00 151197
E317 159332 9.3 480 3 D213T 1.15 82 CL00A310T-U 151148 RTA1-N 8.00 12.00 151193
M3311T-5 158164 7.7 575 3 213T 1.15 81.5 CL00A310T-Y 151149 RTA1-M 5.50 8.50 151192
EE 10 42
EM3313T 159334 26.0 208 3 215T 1.15 85.5 CL04A310M-L 151169 RTA1-V 25.00 32.00 151199
EM3313T 159334 25.0 240 3 215T 1.15 85.5 CL04A310M-S 151166 RTA1-U 21.00 26.00 151198
EM3313T 159334 12.5 480 3 215T 1.15 85.5 CL01A310T-U 151153 RTA1-P 10.00 16.00 151194
M3313T-5 158163 10.4 575 3 215T 1.15 81 CL00A310T-Y 151149 RTA1-P 10.00 16.00 151194
EE 15 43
EFM2513T-8 142440 40.7 208 3 254T 1.15 84 CL06A311M-L 151173 RTA2-E 30.00 43.00 151206
EFM2513T 142441 35.4 240 3 254T 1.15 84 CL06A311M-S 151172 RTA2-E 30.00 43.00 151206
EFM2513T 142441 17.7 480 3 254T 1.15 84 CL25A310T-U 151162 RTA1-T 17.50 22.00 151197
EFM2513T-5 142289 16.0 575 3 254T 1.15 84 CL02A310T-Y 151158 RTA1-P 10.00 16.00 151194
EE 20 44
E452-F2 159187 57.0 208 3 S256T 1.15 84 CL07A311M-L 151176 RTA2-H 54.00 65.00 151203
EFM2515T 142299 47.0 240 3 256T 1.15 84 CL06A311M-S 151172 RTA2-G 42.00 55.00 151202
EFM2515T 142299 23.5 480 3 256T 1.15 84 CL04A310M-U 151167 RTA1-U 21.00 26.00 151198
EFM2515T-5 142300 19.2 575 3 256T 1.15 84 CL25A310T-Y 151163 RTA1-T 17.50 22.00 151197
Motor Data Maximum Mtr Amp Draw Motor P/N (Volts - Phase) IEC Starter
Rated HP Century P/N Frame 1800 RPM 1200 RPM 208-3 240-3 480-3 Manufacturer's P/N Reznor P/N
1/.44 M124 M145T 3.8 2.4 105641 AEG2SP-S17-C-I-H-O 114971
1/.44 M124 M145T 3.4 2.2 105641 AEG2SP-S17-C-I-H-O 114971
1/.44 M109 M145T 1.7 1.1 105642 AEG2SP-S17-E-G-F-O 114972
1.5/.68 M125 N145T 5.4 3.1 105643 AEG2SP-S17-C-K-I-O 114973
1.5/.68 M125 N145T 4.9 2.8 105643 AEG2SP-S17-C-K-I-O 114973
1.5/.68 M104 N145T 2.4 1.4 105644 AEG2SP-S17-E-H-G-O 114974
2/.88 M220 S182T 6.5 4.2 105645 AEG2SP-S17-C-L-K-O 114975
2/.88 M220 S182T 5.9 3.8 105645 AEG2SP-S17-C-L-I-O 114976
2/.88 M207 S182T 3.4 2.1 105646 AEG2SP-S17-E-I-H-O 114977
3/1.3 M221 S184T 9.3 5.3 105647 AEG2SP-S17-C-M-K-O 114978
3/1.3 M221 S184T 8.4 4.8 105647 AEG2SP-S17-C-M-K-O 114978
3/1.3 M208 S184T 4.6 2.6 105648 AEG2SP-S17-E-K-H-O 114979
5/2.2 M320 S215T 17.2 11.3 105870 AEG2SP-S17-C-O-M-O 114980
5/2.2 M320 S215T 15.5 10.2 105870 AEG2SP-S17-C-O-M-O 114980
5/2.2 M305 S215T 7.1 4.8 105871 AEG2SP-S17-E-L-K-O 114981
7.5/3.3 M317 Y215T 21.6 13.6 105872 AEG2SP-S17-C-O-N-O 114982
7.5/3.3 M317 Y215T 19.5 12.3 105872 AEG2SP-S17-C-O-N-O 114982
7.5/3.3 M315 D215T 10.0 6.0 105873 AEG2SP-S17-E-M-L-O 114983
10/4.4 M421 S256T 31.0 19.4 105874 AEG2SP-S17-C-P-O-O 114984
10/4.4 M421 S256T 28.0 17.5 105874 AEG2SP-S17-C-P-O-O 114984
10/4.4 M413 S256T 13.5 7.5 105875 AEG2SP-S17-E-N-L-O 114985
2-Speed
Blower
Motors
IEC Two-Speed Starter
Effective 9/91, IEC two-speed starters are used. Prior to 9/91, units with 2-speed
motors were equipped with NEMA starters. If replacing a NEMA starter with an
IEC starter, replace the complete starter. See terminal cross reference chart
(right).
Original box and cover may be used for replacement IEC starter.
Terminal
Cross-
Reference
Chart for
Replacement
IEC Starters
NEMA IEC
Starter Wire Terminals
High Speed
D 2T1
F 6T3
E 4T2
Low Speed
A 2T1
C 6T3
B 4T2
Relay/Starter Coil Terminals
9 96 95
Replacement Blower Motors and Starters (cont'd) - See replacement information, bottom of page 13.
