Reznor SSCDBL Parts Manuals - Manual (Page 20)

Form P-SC, P/N 269822R3, Page 20
Unit
Sizes
Motor Voltage
Option
Drive AM Nos. Motor Pulley Blower Pulley Belt *Shaft
Centerline HP Opt (See Key, chart on page 17.) P/N Mfr # Bore P/N Mfr # Bore P/N Qty Mfr #
250
300
1 AL45
AK5 (208/3);
AK6 (230/3);
AK7 (460/3)
AM 7, 8, 9, 10, 11 110125 1VP34 7/8 105482 AK56 1 105489 1 A35 12.24
AM 12, 13, 14, 15, 16 110125 1VP34 7/8 105481 AK46 1 101291 1 A33 12.06
1-1/2 AL46
AM 9, 10, 11 106748 1VL40 7/8 18797 AK64 1 105491 1 A37 12.2
AM 12, 13, 14, 15, 16 106758 1VL44 7/8 105482 AK56 1 105490 1 A36 12.06
AM 17, 18, 19, 20, 21, 22, 23 106758 1VL44 7/8 105481 AK46 1 105489 1 A35 12.37
2 AL47
AM 12, 13, 14, 15, 16 111681 1VP50 1-1/8 105483 AK69 1 105493 1 A39 12.04
AM 17, 18, 19, 20 111681 1VP50 1-1/8 115716 AK59 1 105491 A37 11.86
AM 21, 22, 23, 24 111681 1VP50 1-1/8 111689 AK49 1 105490 1 A36 12.16
3 AL48
AM 13, 14, 15, 16 111681 1VP50 1-1/8 105483 AK69 1 105493 1 A39 12.04
AM 17, 18, 19, 20 111681 1VP50 1-1/8 115716 AK59 1 105491 A45 11.86
AM 21, 22, 23, 24 111681 1VP50 1-1/8 111689 AK49 1 105490 1 A36 12.16
350
400
1 AL45
AK5 (208/3);
AK6 (230/3);
AK7 (460/3)
AM 3, 4, 5, 6 110125 1VP34 7/8 105484 AK71HC 1 50500 1 A41 13.98
AM 7, 8, 9, 10, 11 110125 1VP34 7/8 105482 AK56 1 105493 1 A39 14.25
1-1/2 AL46
AM 6, 7, 8, 9 106748 1VL40 7/8 105484 AK71HC 1 101412 1 A42 14.12
AM 10, 11, 12, 13 106758 1VL44 7/8 18797 AK64 1 16019 1 A40 13.91
AM 14, 15, 16, 17, 18 106748 1VL40 7/8 105481 AK46 1 16018 1 A38 14.18
2 AL47
AM 12, 13, 14, 15, 16 111681 1VP50 1-1/8 105483 AK69 1 50470 1 A43 14.05
AM 17, 18, 19, 20 111681 1VP50 1-1/8 105482 AK56 1 50500 1 A41 14.11
AM 21, 22, 23, 24 111681 1VP50 1-1/8 111689 AK49 1 16019 1 A40 14.16
3 AL48
AM 12, 13, 14, 15, 16 111681 1VP50 1-1/8 105483 AK69 1 50470 1 A43 14.05
AM 17, 18, 19, 20 111681 1VP50 1-1/8 105482 AK56 1 50500 1 A41 14.11
AM 21, 22, 23, 24 111681 1VP50 1-1/8 111689 AK49 1 16019 1 A40 14.16
5 AL10
AM 12, 13, 14, 15, 16, 17 6599 2VP42 7/8 7955 2AK104 1 65403 2 A48 14.11
AM 18, 19, 20, 21, 22 8973 2VP50 7/8 7955 2AK104 1 50472 2 A49 14.06
Drive
Components
- Model
SSCBL with
Open Motor
(See drive
information,
top of page
17.)
Unit
Sizes
Motor
Voltage Option
Drive AM Nos. Motor Pulley Blower Pulley Belt *Shaft
Centerline HP Opt (See Key, chart page 17.) P/N Mfr # Bore P/N Mfr # Bore P/N Qty Mfr #
All
"BL"
Units
1 AL6
AK1 (115/1); AK2 (208/1);
AK3 (230/1); AK5 (208/3);
AK6 (230/3); AK7 (460/3);
AK8 (575/3)
AM 2, 3, 4 13580 1VL34 5/8 111862 AK84 1-3/16 16134 1 A57 20.94
AM 5, 6, 7 13580 1VL34 5/8 105484 AK71HA 1-3/16 16134 1 A57 21.03
1-1/2 AL7
AM 3, 4, 5, 6, 7 13580 1VL34 5/8 105484 AK71HA 1-3/16 16134 1 A57 21.03
AM 8, 9, 10, 11 105476 1VL44 5/8 106256 AK74 1-3/16 16134 1 A57 21.11
2 AL8
AM 3, 4, 5, 6, 7 110125 1VP34 7/8 105484 AK71HA 1-3/16 16132 1 A55 20.03
AM 8, 9, 10, 11 106758 1VL44 7/8 105484 AK71HA 1-3/16 16133 1 A56 20.85
AM 12, 13, 14, 15, 16 106758 1VL44 7/8 110807 AK56HA 1-3/16 16131 1 A54 21.07
3 AL9
AK2 (208/1); AK3 (230/1);
AK5 (208/3); AK6 (230/3);
AK7 (460/3); AK8 (575/3)
AM 7, 8, 9 37451 1VM50 7/8 16160 AK184 1-3/16 92264 1 A78 20.95
AM 10, 11, 12, 13 106758 1VL44 7/8 16158 AK134 1-3/16 16558 1 A69 20.96
AM 14, 15, 16, 17, 18 37451 1VM50 7/8 16156 AK124 1-3/16 111870 1 A66 20.92
5 AL10
AK5 (208/3); AK6 (230/3);
AK7 (460/3); AK8 (575/3)
AM 8,9,10,11 6599 2VP42 7/8 16161 2AK134 1-3/16 92408 1 A68 21.08
AM 12,13,14,15 87500 2VP36 7/8 16003 2BK100 1-3/16 88560 1 A61 21.01
AM 16, 17, 18, 19, 20 6599 2VP42 7/8 16003 2BK100 1-3/16 16137 1 A62 21.08
7-1/2 AL11
AM 10, 11 16150 2VP62 1-3/8 16168 2BK110 1-3/16 92414 1 B64 20.47
AM 12, 13 16150 2VP62 1-3/8 16003 2BK100 1-3/16 7950 1 B62 20.31
AM 14, 15, 16 16150 2VP62 1-3/8 91633 2TB86 B 1-3/16 92280 1 BX59 20.47
AM 17, 18, 19, 20 110771 2VP65 1-3/8 89648 2BK80HA 1-3/16 92280 1 BX59 20.37
10 AL12
AM 10, 11 16150 2VP62 1-3/8 16168 2BK110 1-3/16 92414 1 B64 20.47
AM 12, 13 16150 2VP62 1-3/8 16003 2BK100 1-3/16 7950 1 B62 20.31
AM 14,15,16 16150 2VP62 1-3/8 91633 2TB86 B 1-3/16 92280 1 BX59 20.47
AM 17, 18, 19, 20 110771 2VP65 1-3/8 89648 2BK80HA 1-3/16 92280 1 BX59 20.37
**15 AL15
AK5 (208/3); AK6 (230/3);
AK7 (460/3); AK8 (575/3)
**AM 15, 16, 17, 18, 19, 20 89644 3MVPP40-B54 1-5/8 106258 3TB66H G 1-7/16 92224 3 B56 20.47
**AM 21, 22, 23, 24 89644 3MVPP40-B54 1-5/8 106262 3BK65H C 1-7/16 92224 3 B56 20.53
**20 AL16
**AM 17, 18, 19, 20, 21,
22, 23, 24
89644 3MVPP40-B54 1-5/8 106262 3BK65H C 1-7/16 92239 3 BX54 20.11
***15 AL15
***AM 15, 16, 17 148593 E 2MVP70B84P 1-5/8" 113811 2BK120H D 1-7/16 80841 2 BX67 20.47
***AM 18, 19, 20, 21 148594 F 2MVP80B94Q 1-5/8" 114045 2B5V110 G 1-7/16 148605 2 BX69 20.53
***AM 22, 23, 24 148593 E 2MVP70B84P 1-5/8" 148597 2B5V90 G 1-7/16 114258 2 BX64 20.11
***20 AL16
***AM17 148593 E 2MVP70B84P 1-5/8" 113811 2BK120H D 1-7/16 80841 2 BX67
***AM 18, 19, 20, 21 148594 F 2MVP80B94Q 1-5/8" 114045 2B5V110 G 1-7/16 148605 2 BX69
***AM 22, 23, 24 148593 E 2MVP70B84P 1-5/8" 148597 2B5V90 G 1-7/16 114258 2 BX64
*Distance between blower shaft and motor centerline with belts tensioned properly. ** Three-Groove Drives ***Two-Groove Drives
Drive Components for Totally Enclosed Motors (See drive information, top of page 17.)
Unit
Sizes
Motor
Voltage Option
Drive AM Nos. Motor Pulley Blower Pulley Belt *Shaft
Centerline HP Opt (See Key, chart on page 17) P/N Mfr # Bore P/N Mfr # Bore P/N Qty Mfr #
All
"BL"
1 AL23
AK1 (115/1); AK2 (208/1); AK3 (230/1); AK5
(208/3); AK6 (230/3); AK7 (460/3);
AK8 (575/3)
AM 2, 3, 4 13580 1VL34 5/8 111862 AK84 1-3/16 16134 1 A57 20.94
AM 5, 6, 7 13580 1VL34 5/8 105484 AK71H C 1-3/16 16134 1 A57 21.03
1-1/2 AL24
AK1 (115/1); AK2 (208/1); AK3 (230/1);
AK5 (208/3); AK6 (230/3); AK7 (460/3)
AM 3, 4, 5 ,6, 7 13580 1VL34 5/8 105484 AK71H C 1-3/16 16134 1 A57 21.03
AM 8, 9, 10, 11 105476 1VL44 5/8 106256 AK74 1-3/16 16134 1 A57 21.11
AK8 (575/3)
AM 3, 4, 5 ,6, 7 110125 1VP34 7/8 105484 AK71H C 1-3/16 16134 1 A57 21.03
AM 8, 9, 10, 11 106758 1VL44 7/8 106256 AK74 1-3/16 16134 1 A57 21.11
2 AL25
AK1 (115/1); AK3 (230/1); AK5 (208/3);
AK6 (230/3); AK7 (460/3); AK8 (575/3)
AM 3, 4, 5, 6, 7 110125 1VP34 7/8 105484 AK71H C 1-3/16 16132 1 A55 20.03
AM 8, 9, 10, 11 106758 1VL44 7/8 105484 AK71H C 1-3/16 16133 1 A56 20.85
AM 12, 13, 14, 15, 16 106758 1VL44 7/8 110807 AK56H C 1-3/16 16131 1 A54 21.07
3 26
AK1 (115/1); AK3 (230/1); AK5 (208/3);
AK6 (230/3); AK7 (460/3)
AM 7, 8, 9 37451 1VM50 7/8 16160 AK184 1-3/16 92264 1 A78 20.95
AM 10, 11, 12, 13 106758 1VL44 7/8 16158 AK134 1-3/16 16558 1 A69 20.96
AM 14, 15, 16, 17, 18 37451 1VM50 7/8 16156 AK124 1-3/16 111870 1 A66 20.92
All
"BL"
3 AL26 AK8 (575/3)
AM 7, 8, 9 37451 1VM50 7/8 16160 AK184 1-3/16 92264 1 A78 20.95
AM 10, 11, 12, 13 106758 1VL44 7/8 16158 AK134 1-3/16 16558 1 A69 20.96
AM 14, 15, 16, 17, 18 37451 1VM50 7/8 16156 AK124 1-3/16 111870 1 A66 20.92
5 AL27
AK3 (230/1); AK5 (208/3); AK6 (230/3);
AK7 (460/3); AK8 (575/3)
AM 8 ,9, 10, 11 7963 2VP42 1-1/8 16161 2AK134 1-3/16 16139 1 A67 21.08
AM 12, 13, 14, 15 105581 2VP50 1-1/8 16161 2AK134 1-3/16 92408 1 A68 21.01
AM 16, 17, 18, 19, 20 7963 2VP42 1-1/8 16003 2BK100 1-3/16 50477 1 A60 21.08
Drive
Components
(cont'd) -
Model SCE
Series with
Two-Speed
Motor
(See drive
information, top
of page 17.)
A Use 1-3/16 "H" Blower Pulley Bushing, P/N 106260; B Use 1-3/16 "Q1" Blower Pulley Bushing, P/N 39460; C Use 1-7/16 "H" Blower Pulley Bushing, P/N 89659; D Use 1-7/16 "B" Blower Pulley
Bushing, P/N 114033; E Use 1-5/8 "P2" Motor Pulley Bushing, P/N 148595; F Use 1-5/8 "Q2" Motor Pulley Bushing, P/N 148596; G Use 1-7/16 "P1" Blower Pulley Bushing, P/N 106261;
