Form P-SC, P/N 269822R3, Page 2
Rating Plate and Serial No.
Serial No.
Codes
BAA 66 H5 N 00000
1 2 3 4 5
1 - Date of manufacture (below)
2 - Type of pilot system (see Form P-VALVES)
3 - Type of gas valve (see Form P-VALVES)
4 - Gas (N= natural; L = propane)
5 - Consecutive number (identification only )
Key to Rating Plate Codes
AA-A = ANSI Code and Date
AA'-A' = CSA Code and Date
B = Model No.
C = Date of Manufacture
D = Serial No.
E = Volts, Phase, Hz, Amps
F = Type of Gas
H = Altitude (feet)
I = Altitude (meters)
J = Orifice Size
K = Normal Input Altitude
Adjusted (BTUH)
L = Thermal Output Altitude
Adjusted (BTUH)
M = Minimum Input Altitude
Adjusted (BTUH)
N = Normal Manifold Pressure
("w.c.)
O = Minimum Gas Supply
Pressure ("w.c.)
P = Maximum Air Throughput
(CFM)
Q = Minimum Air Throughput
(CFM)
R = Normal Input Sea Level
(BTUH)
S = Thermal Output Sea Level
(BTUH)
T = Minimum Input Sea Level
(BTUH)
X = Pipe Diameter (inches)
Y = Maximum Combined Length
(inches)
REZNOR
MERCER, PA. USA 16137
MADE IN MEXICO
SEPARATED COMBUSTION SYSTEM
DUCT FURNACE
CATEGORY III
FOR INDUSTRIAL/COMMERCIAL USE ONLY
ANSI Z83.8 [ AA ] - [ A ] CSA 2.6 [ AA' ] - [ A' ] DUCT FURNACE
MODEL [ B ] [ C ]
SERIAL NO. [ D ]
WIRING DIAGRAM NUMBER [ Z ]
[ E ] VOLTS [ E ] PH [ E ] HZ MAXIMUM TOTAL INPUT [ E ] AMPS
TYPE OF GAS: [ F ]
ORIFICE SIZE [ J ] DRILL HAS BEEN FACTORY ADJUSTED
FOR USE AT [ H ] FEET [ I ] METERS OF ALTITUDE
SEA LEVEL ALT. ADJUSTED
NORMAL INPUT [ R ] [ K ] BTU/HR.
THERMAL OUTPUT CAPACITY [ S ] [ L ] BTU/HR.
MINIMUM INPUT(2,M,MV MODELS) [ T1 or T2 ] [ M ] BTU/HR.
NORMAL MANIFOLD PRESSURE [ N ] IN.W.C.
MIN. PERMISSIBLE GAS SUPPLY PRESSURE
FOR PURPOSE OF INPUT ADJUSTMENT. [ O ] IN.W.C.
MAXIMUM THROUGHPUT [ P ] CFM.
MINIMUM THROUGHPUT [ Q ] CFM.
CLEARANCES TO COMBUSTIBLE CONSTRUCTION: FLUE CONN. -6",
SERVICE SIDE-WIDTH OF UNIT, OPP. SIDE-6", BOTTOM-6", TOP-6"
MAY BE INSTALLED ON NONCOMBUSTIBLE FLOORS.
INSTALL ON THE POSITIVE PRESSURE SIDE OF AIR-CIRCULATING BLOWER.
THIS UNIT MAY BE INSTALLED DOWNSTREAM FROM A REFRIGERATION
SYSTEM (USE DRAIN OPTION CS1).
THIS UNIT MAY BE VENTED VERTICALLY WHEN USING CONCENTRIC
ADAPTOR ASSEMBLY, PART NO. 82131, SUPPLIED BY REZNOR.
FOR ALTERNATE INSTALLATIONS USE THE LATEST EDITIONS OF THE
APPROPRIATE STANDARD LISTED BELOW:
FOR AIRCRAFT HANGARS USE STANDARD ANSI/NFPA 409
FOR PARKING STRUCTURES USE STANDARD ANSI/NFPA 88A
FOR REPAIR GARAGES USE STANDARD ANSI/NFPA 88B
THIS UNIT IS FOR CONNECTION MINIMUM OF 10'-0" OR THE FOLLOWING
MAXIMUM LENGTHS:
[ X ] IN. PIPE DIA. [ Y ] FEET MAX. COMBINED LENGTH
Year Jan Feb Mar Apr May June July Aug Sept Oct Nov Dec
1974 ZA ZB ZC ZD ZE ZF ZG ZH ZI ZJ ZK ZL
1975 AAA AAB AAC AAD AAE AAF AAG AAH AAI AAJ AAK AAL
1976 ABA ABB ABC ABD ABE ABF ABG ABH ABI ABJ ABK ABL
1977 ACA ACB ACC ACD ACE ACF ACG ACH ACI ACJ ACK ACL
1978 ADA ADB ADC ADD ADE ADF ADG ADH ADI ADJ ADK ADL
1979 AEA AEB AEC AED AEE AEF AEG AEH AEI AEJ AEK AEL
1980 AFA AFB AFC AFD AFE AFF AFG AFH AFI AFJ AFK AFL
1981 AGA AGB AGC AGD AGE AGF AGG AGH AGI AGJ AGK AGL
1982 AHA AHB AHC AHD AHE AHF AHG AHH AHI AHJ AHK AHL
1983 AIA AIB AIC AID AIE AIF AIG AIH AII AIJ AIK AIL
1984 AJA AJB AJC AJD AJE AJF AJG AJH AJI AJJ AJK AJL
1985 AKA AKB AKC AKD AKE AKF AKG AKH AKI AKJ AKK AKL
1986 ALA ALB ALC ALD ALE ALF ALG ALH ALI ALJ ALK ALL
1987 AMA AMB AMC AMD AME AMF AMG AMH AMI AMJ AMK AML
1988 ANA ANB ANC AND ANE ANF ANG ANH ANI ANJ ANK ANL
1989 AOA AOB AOC AOD AOE AOF AOG AOH AOI AOJ AOK AOL
1990 APA APB APC APD APE APF APG APH API APJ APK APL
1991 AQA AQB AQC AQD AQE AQF AQG AQH AQI AQJ AQK AQL
1992 ARA ARB ARC ARD ARE ARF ARG ARH ARI ARJ ARK ARL
1993 ASA ASB ASC ASD ASE ASF ASG ASH ASI ASJ ASK ASL
1994 ATA ATB ATC ATD ATE ATF ATG ATH ATI ATJ ATK ATL
1995 AUA AUB AUC AUD AUE AUF AUG AUH AUI AUJ AUK AUL
1996 AVA AVB AVC AVD AVE AVF AVG AVH AVI AVJ AVK AVL
1997 AWA AWB AWC AWD AWE AWF AWG AWH AWI AWJ AWK AWL
1998 AXA AXB AXC AXD AXE AXF AXG AXH AXI AXJ AXK AXL
1999 AYA AYB AYC AYD AYE AYF AYG AYH AYI AYJ AYK AYL
2000 AZA AZB AZC AZD AZE AZF AZG AZH AZI AZJ AZK AZL
2001 BAA BAB BAC BAD BAE BAF BAG BAH BAI BAJ BAK BAL
2002 BBA BBB BBC BBD BBE BBF BBG BBH BBI BBJ BBK BBL
2003 BCA BCB BCC BCD BCE BCF BCG BCH BCI BCJ BCK BCL
2004 BDA BDB` BDC BDD BDE BDF BDG BDH BDI BDJ BDK BDL
2005 BEA BEB BEC BED BEE BEF BEG BEH BEI BEJ BEK BEL
2006 BFA BFB BFC BFD BFE BFF BFG BFH BFI BFJ BFK BFL
2007 BGA BGB BGC BGD BGE BGF BGG BGH BGI BGJ BGK BGL
2008 BHA BHB BHC BHD BHE BHF BHG BHH BHI BHJ BHK BHL
2009 BIA BIB BIC BID BIE BIF BIG BIH BII BIJ BIK BIL
2010 BJA BJB BJC BJD BJE BJF BJG BJH BJI BJJ BJK BJL
2011 BKA BKB BKC BKD BKE BKF BKG BKH BKI BKJ BKK BKL
2012 BLA BLB BLC BLD BLE BLF BLG BLH BLI BLJ BLK BLL
2013 BMA BMB BMC BMD BME BMF BMG BMH BMI BMJ BMK BML
2014 BNA BNB BNC BND BNE BNF BNG BNH BNI BNJ BNK BNL
2015 BOA BOB BOC BOD BOE BOF BOG BOH BOI BOJ BOK BOL
2016 BPA BPB BPC BPD BPE BPF BPG BPH BPI BPJ BPK BPL
2017 BQA BQB BQC BQD BQE BQF BQG BQH BQI BQJ BQK BQL
2018 BRA BRB BRC BRD BRE BRF BRG BRH BRI BRJ BRK BRL
2019 BSA BSB BSC BSD BSE BSF BSG BSH BSI BSJ BSK BSL
2020 BTA BTB BTC BTD BTE BTF BTG BTH BTI BTJ BTK BTL
First Element
of the Serial
Number - Date
of Manufacture
