Page 26: Models sscbl and sscdbl
Form P-SC, P/N 269822R3, Page 26
A
B
C
D
A
D
D
D
C
C
C
Blockoff
Plates
C
C
C
C
A
B
D
D
D
D
Blockoff
Plates
C
C
C
C
A
A
B
B
B
B
Blockoff
Plates
A
B
C
C
C
C
D
D
D
D
Blockoff
Plate
B
B
B
B
B
B
B
B
A
A
Blockoff
Plate
D
D
D
D
B
A
A
C
C
C
C
C
C
C
C
Blockoff
Plate
B
A
A
D
D
D
D
C
C
C
C
Blockoff
Plates
B
C
C
C
C
A
D
D
D
D
Blockoff
Plates
A
A
B
B
B
B
C
C
C
C
Blockoff
Plate
Blower, Bearing Support, and Motor on unit with
up to a 5 HP Motor
308
319
Motor Mounting Base
Motor Mounting Base
Retaining Clip,
P/N 112570
Retaining Clip,
P/N 112572
Star Washer
P/N 112571
Star Washer
P/N 112573
3/8 Bolt,
P/N 32253
5/16 Bolt,
P/N 16247
Code 320 - Motor Mounting Bolts
3/8" Bolt
5/16" Bolt
Blower Triangular Bearing Mounting for SSCBL
with a 7-1/2 or 10 HP Motor
Description
P/N
Left Bearing Support Assy
112971
Right Bearing Support Assy
112972
Pillowblock Bearing Sealmaster 1/16" (2)
112973
90° Grease Fitting
195834
1/2-13 x 2" Cap Screw GR-8
(4)
111304
1/2-13 Nut GR-8
(4)
111305
1/2 Lockwasher
(4)
111306
1/4-20 Cap Screws
(6)
16246
1/4-20 Lock Nut
(6)
10650
Blower and
Bearing on
a unit with a
15 and 20 HP
Motor (See
CODES 330-
338)
CODE 339 - Sensing
Tube Assembly,
P/N 111733
10
(254mm)
1 (25mm)
Airflow
IMPORTANT: Sensing
tube must point into airflow.
Location of Optional Air Flow
Switch Sensor, CODE 339
Replacement
Filters/
Blockoff
Plates -
Models
SSCBL
and
SSCDBL
SSCBL 400, 800, 1200;
SSCDBL 800, 1600 (2 sets)
A
16 x 16
B
16 x 25
C
12 x 25
D
12 x 30
SSCBL 500, 600;
SSCDBL 1000, 1200 (2 sets)
SSCBL 700, 1050;
SSCDBL 1400 (2 sets)
Filter Arrangements for 1" or 2" Disposable Filters (Options AW2 and AW7)
Blockoff Plates:
(1)
P/N 106334;
(4)
P/N 114337
Blockoff Plates:
(1)
P/N 106332;
(4)
P/N 114336
Blockoff Plates:
(1)
P/N 106332;
(4)
P/N 114336
A
16 x 16
B
16 x 25
C
12 x 20
D
12 x 25
A
16 x 25
B
12 x 20
C
12 x 30
SSCBL 400, 800, 1200;
SSCDBL 800, 1600 (2 sets)
SSCBL 400, 800, 1200;
SSCDBL 800, 1600 (2 sets)
SSCBL 500, 600;
SSCDBL 1000, 1200 (2 sets)
SSCBL 500, 600;
SSCDBL 1000, 1200 (2 sets)
SSCBL 700, 1050;
SSCDBL 1400 (2 sets)
SSCBL 700, 1050;
SSCDBL 1400 (2 sets)
Filter Arrangements for 1" or 2" Disposable Pleated Filters (Options AW10 and AW11)
Filter Arrangements for 1" or 2" Permanent Filters (Options AW8 and AW9)
Blockoff Plates:
(1)
P/N 106334;
(4)
P/N 114335
Blockoff Plates:
(1)
P/N 106332;
(4)
P/N 114337
Blockoff Plate:
(1)
P/N 106333
Blockoff Plate:
(1)
P/N 106334
Blockoff Plate:
(1)
P/N 106334
Blockoff Plate:
(1)
P/N 106332
A
16 x 16
B
16 x 25
C
12 x 25
D
12 x 32
A
16 x 20
B
16 x 25
C
12 x 20
D
12 x 25
A
16 x 25
B
12 x 20
C
12 x 32
A
16 x 16
B
16 x 25
C
12 x 16
D
12 x 26
A
16 x 20
B
16 x 25
C
12 x 20
D
12 x 26
A
16 x 25
B
12 x 26
Model SSCBL Blower Cabinet and Blower Parts (cont'd)
Filter P/N's
- top of
page 27
