Form P-SC, P/N 269822R3, Page 15
Open Motor (cont'd) Frame
Size
Service
Factor
Power
Factor
Starter (AN10) Starter Overload
Type HP AL Mfr's #. P/N fla volt ph Mfr # P/N Mfr # min max P/N
Open 15 15
FM2513T-8 142287 43.1 208 3 254T 1.15 80 CL06A311M-L 151173 RTA2-G 42.00 55.00 151202
FM2513T 142288 39.0 240 3 254T 1.15 80 CL06A311M-S 151172 RTA2-E 30.00 43.00 151206
FM2513T 142288 19.5 480 3 254T 1.15 80 CL25A310T-U 151162 RTA1-T 17.50 22.00 151197
FM2513T-5 142289 16.0 575 3 254T 1.15 80 CL02A310T-Y 151158 RTA1-S 14.50 18.00 151196
Open 20 16
FM2515T-8 142295 58.7 208 3 256T 1.15 80 CL07A311M-L 151176 RTA2-H 54.00 65.00 151203
FM2515T 142296 53.0 240 3 256T 1.15 81 CL07A311M-S 151175 RTA2-G 42.00 55.00 151202
FM2515T 142296 26.5 480 3 256T 1.15 81 CL04A310M-U 151167 RTA1-V 25.00 32.00 151199
FM2515T-5 142297 21.2 575 3 256T 1.15 80 CL25A310T-Y 151163 RTA1-T 17.50 22.00 151197
TEFC Motor Frame
Size
Service
Factor
Power
Factor
Starter (AN10) Starter Overload
Type HP AL Mfr's #. P/N fla volt ph Mfr # P/N Mfr # min max P/N
TEFC 1/4 19
#904 105566 3.6 120 1 M48 1 CL00A310T-J 151146 RTA1-K 2.50 4.10 151190
C199 16074 2.2 208 1 H56 1.35 CL00A310T-L 151150 RTA1-J 1.90 2.70 151189
C199 16074 2.6 240 1 H56 1.35 CL00A310T-S 151147 RTA1-H 1.30 1.90 151188
125439 16075 1.6 208 3 B56 1 61.9 CL00A310T-L 151150 RTA1-H 1.30 1.90 151188
125439 16075 1.4 240 3 B56 1 61.9 CL00A310T-S 151147 RTA1-G 1.00 1.50 151187
125439 16075 0.7 480 3 B56 1 61.9 CL00A310T-U 151148 RTA1-F 0.65 1.10 151186
TEFC 1/3 20
#906L 115861 4.6 120 1 N48 1 68.5 CL00A310T-J 151146 RTA1-L 4.00 6.30 151191
C151 159501 2.3 208 1 N48 1 67.2 CL00A310T-L 151150 RTA1-J 1.90 2.70 151189
C151 159501 2.4 240 1 N48 1 67.2 CL00A310T-S 151147 RTA1-J 1.90 2.70 151189
H261 105567 1.2 208 3 L48 1.15 CL00A310T-L 151150 RTA1-G 1.00 1.50 151187
H261 105567 1.2 240 3 L48 1.15 CL00A310T-S 151147 RTA1-G 1.00 1.50 151187
H261 105567 0.6 480 3 L48 1.15 CL00A310T-U 151148 RTA1-D 0.40 0.65 151184
TEFC 1/2 21
C613 159184 7.2 120 1 J56 1.15 CL00A310T-J 151146 RTA1-M 5.50 8.50 151192
C613 159184 3.5 208 1 J56 1.15 CL00A310T-L 151150 RTA1-K 2.50 4.10 151190
C613 159184 3.6 240 1 J56 1.15 CL00A310T-S 151147 RTA1-K 2.50 4.10 151190
H274 16077 2.3 208 3 H56 1 59.5 CL00A310T-L 151150 RTA1-J 1.90 2.70 151189
H274 16077 2.0 240 3 H56 1 59.5 CL00A310T-S 151147 RTA1-J 1.90 2.70 151189
H274 16077 1.0 480 3 H56 1 59.5 CL00A310T-U 151148 RTA1-F 0.65 1.10 151186
H276 105568 0.7 575 3 J56 1.15 76.4 CL00A310T-Y 151149 RTA1-F 0.65 0.90 151186
TEFC 3/4 22
F353 115860 11.0 120 1 F56 1 66 CL01A310T-J 151151 RTA1-P 10.00 16.00 151194
F353 115860 5.4 208 1 F56 1 66 CL00A310T-L 151150 RTA1-L 4.00 6.30 151191
F353 115860 5.5 240 1 F56 1 66 CL00A310T-S 151147 RTA1-L 4.00 6.30 151191
H580 20371 2.0 208 3 KA56 1 73.5 CL00A310T-L 151150 RTA1-J 1.90 2.70 151189
H580 20371 2.2 240 3 KA56 1 73.5 CL00A310T-S 151147 RTA1-J 1.90 2.70 151189
H580 20371 1.1 480 3 KA56 1 73.5 CL00A310T-U 151148 RTA1-G 1.00 1.50 151187
H461 105569 0.8 575 3 L56 1.15 78.3 CL00A310T-Y 151149 RTA1-F 0.65 1.10 151186
TEFC 1 23
159105 174993 12.0 120 1 L56 1.15 74.3 CL01A310T-J 151151 RTA1-P 10.00 16.00 151194
159105 174993 6.2 208 1 L56 1.15 74.3 CL00A310T-S 151147 RTA1-M 5.50 8.50 151192
159105 174993 6.0 240 1 L56 1.15 74.3 CL00A310T-S 151147 RTA1-M 5.50 8.50 151192
H524 16080 3.3 208 3 J56 1 74.4 CL00A310T-L 151150 RTA1-K 2.50 4.10 151190
H524 16080 3.4 240 3 J56 1 74.4 CL00A310T-S 151147 RTA1-K 2.50 4.10 151190
H524 16080 1.7 480 3 J56 1 74.4 CL00A310T-U 151148 RTA1-H 1.30 1.90 151188
H525 105570 1.4 575 3 H56 1.15 71.6 CL00A310T-Y 151149 RTA1-G 1.00 1.50 151187
TEFC 1.5 24
C686 94347 16.4 120 1 TK56H CL02A310T-J 151156 RTA1-S 14.50 18.00 151196
C686 94347 9.5 208 1 TK56H CL00A310T-L 151150 RTA1-N 8.00 12.00 151193
C686 94347 8.2 240 1 TK56H CL00A310T-S 151147 RTA1-N 8.00 12.00 151193
H535 101286 4.3 208 3 L56H 1 80.9 CL00A310T-L 151150 RTA1-L 4.00 6.30 151191
H535 101286 4.4 240 3 L56H 1 80.9 CL00A310T-S 151147 RTA1-L 4.00 6.30 151191
H535 101286 2.2 480 3 L56H 1 80.9 CL00A310T-U 151148 RTA1-J 1.90 2.70 151189
E127 105665 1.6 575 3 M145T 1.15 85.7 CL00A310T-Y 151149 RTA1-H 1.30 1.90 151188
TEFC 2 25
C687 105572 24.0 120 1 F182T 1 76.4 CL04A310M-J 151165 RTA1-U 21.00 26.00 151198
L3516TM 205881 8.3 240 1 56HZ 1 76.4 CL01A310T-S 151152 RTA1-P 10.00 16.00 151194
M3587T 158165 6.3 208 3 145T 1.15 77.5 CL00A310T-L 151150 RTA1-M 5.50 8.50 151192
M3587T 158165 5.8 240 3 145T 1.15 77.5 CL00A310T-S 151147 RTA1-L 4.00 6.30 151191
M3587T 158165 2.9 480 3 145T 1.15 77.5 CL00A310T-U 151148 RTA1-K 2.50 4.10 151190
M3587T-5 158166 2.2 575 3 145T 1.15 77.5 CL00A310T-Y 151149 RTA1-J 1.90 2.70 151189
TEFC 3 26
K222 111564 30.0 120 1 F184T 1 88 CL04A310M-J 151165 RTA1-V 25.00 32.00 151199
K222 111564 15.0 240 1 F184T 1 88 CL02A310T-S 151157 RTA1-P 10.00 16.00 151194
M3559T 159330 7.9 208 3 145T 1.15 CL00A310T-L 151150 RTA1-M 5.50 8.50 151192
M3559T 159330 7.2 240 3 145T 1.15 CL00A310T-S 151147 RTA1-M 5.50 8.50 151192
M3559T 159330 3.6 480 3 145T 1.15 CL00A310T-U 151148 RTA1-K 2.50 4.10 151190
M3660T-5 158168 3.0 575 3 182T 1.15 CL00A310T-Y 151149 RTA1-K 2.50 4.10 151190
TEFC 5 27
K223 111567 20.2 240 1 F184T 1 90.8 CL04A310M-S 151166 RTA1-T 17.50 22.00 151197
M3663T 155048 12.8 208 3 184T 1.15 CL01A310T-L 151155 RTA1-S 14.50 18.00 151196
M3663T 155048 11.8 240 3 184T 1.15 CL01A310T-S 151152 RTA1-P 10.00 16.00 151194
M3663T 155048 5.9 480 3 184T 1.15 CL00A310T-U 151148 RTA1-L 4.00 6.30 151191
M3663T-5 158170 4.8 575 3 184T 1.15 90 CL00A310T-Y 151149 RTA1-L 4.00 6.30 151191
TEFC 7.5 32
K305 105842 34.0 240 1 F215T 1 86.5 CL45A310M-S 151170 RTA1-W 30.00 40.00 151200
T4631 158171 21.0 208 3 213T 1.15 83.1 CL04A310M-L 151169 RTA1-U 21.00 26.00 151198
T4631 158171 19.0 240 3 213T 1.15 83.1 CL25A310T-S 151161 RTA1-T 17.50 22.00 151197
TEFC 7.5 32
T4631 158171 9.5 480 3 213T 1.15 83.1 CL01A310T-U 151153 RTA1-N 8.00 12.00 151193
M3710T-5 158172 8.1 575 3 213T 1.15 83.1 CL00A310T-Y 151149 RTA1-M 5.50 8.50 151192
TEFC 10 33
K313 105846 39.0 240 1 215T 1 96.5 CL06A311M-S 151172 RTA2-E 30.00 43.00 151206
M3774T 158173 39.0 208 3 215T 1.15 85 CL04A310M-L 151169 RTA1-V 25.00 32.00 151199
M3774T 158173 20.0 240 3 215T 1.15 85 CL04A310M-S 151166 RTA1-U 21.00 26.00 151198
M3774T 158173 10.0 480 3 215T 1.15 85 CL01A310T-U 151153 RTA1-P 10.00 16.00 151194
M3774T-5 158174 11.4 575 3 215T 1.15 85 CL01A310T-Y 151154 RTA1-N 8.00 12.00 151193
