PROHEAT INSTALLATION & SERVICE

5-2

The ON/OFF switch (or Timer) lamp and the PCM “ON” LED will light. In addition,

the Hour Meter (Auxiliary Output) will be powered. The PROHEAT goes to

“Precheck”.

EXAMPLE PROHEAT BEHAVIOR ERROR – CODE 01

5.0.2

1. Switch “ON”

Standard

Mode Signal

The PCM performs a short diagnostic cycle. This takes several seconds

checking components for proper ranges, checking for the presence of a

flame, short-circuits and open circuits. If there are no errors indicated, the

PROHEAT goes to “Ignition”.

2. Pre-check

The blower starts first, followed by the coolant pump, ignition spark, air

compressor and fuel pump. The ignition electrode sparks for 60 seconds.

3. Ignition

After two consecutive Code 01 errors, the PROHEAT goes into a hold state.

No further start attempts will be made. Code 01 will be displayed

continuously and the PCM LED “ON” light will turn “OFF.” In addition, the

Hour Meter (Auxiliary Output) will shut off.

The switch, timer red manual light or OEM indicator light will continue to flash

once, pause, flash and repeat.

NOTE: In order to restart the heater turn the switch “OFF” and back “ON”.

6. Hold State

The PROHEAT always restarts after one error detection (except for Codes 13

and 14). After the 3 minute Cool Down (Purge), the PROHEAT will go through

Precheck, Ignition and the Error Detection – Cool Down (Purge) cycle one

more time.

5. Steps 1 to 4

are Repeated

If the flame sensor did not “see” a flame in 60 seconds after entering

ignition, the air compressor and fuel pump shut off immediately. The blower

and coolant pump continue to run.

Code 01 will be displayed alternating with Pu. There will be one flash, pause

and then one flash repeating on the switch, timer red manual light or OEM

indicator light. After 3 minutes, the blower stops and the PROHEAT attempts

to start again.

NOTE: Codes 13 and 14 will not cause the heater to shut down. The PROHEAT

reports the error and continues to run.

4. Error

Detection –

Purge

The following is an example of an X45 PROHEAT behavior during an error.

The following example shows the sequence of events when the PROHEAT is

switch “ON” in the Standard Mode (similar for Preheat and Supplemental

Modes). This sequence of events occurs for Codes 01 through 12. Codes 13

and 14 do not put the heater into Cool Down (Purge) mode or shut down the

PROHEAT; rather, the PROHEAT reports the error and continues to run.
