Page 101
PROHEAT INSTALLATION & SERVICE
6-6
Figure 6-9
Nozzle Components
CLEAN NOZZLE
BLOW THIS DIRECTION
WHEN USING
COMPRESSED AIR.
TORQUE TO
30±3 IN/LBS
(3.4±0.3 Nm)
HOLD
UPRIGHT TO
ASSEMBLE
REPLACE COMPRESSOR AIR FILTER
• Replace inlet air filter annually or more often
if dusty conditions are encountered.
TORQUE TO 50±5 IN/LBS (5.6±0.7 Nm)
• Remove and install Nozzle as shown on page 5-12.
Torque to 150±10 in/lbs (17±1.1 Nm).
• To properly clean the nozzle use electrical
contact cleaner or warm soapy water.
This will wash any dirt out and leave
no residue. When using compressed
air, blow into the nozzle orifice
from the head end.
Figure 6-10
Compressor Air Filter
6.2.10
6.2.9
