Chapter 5: KGUARD Web Client
DVR User’s Manual
67
Time
(24-hour format)
Day
Select recording type
Note:
Recording type buttons are only enabled if Motion/Time is selected in Mode.
4
Click a recording type, selected button turns amber.
• Motion: To record the video only when motion is detected within the specified time. If motion is not detected,
the recording is not performed. See
“Motion Detection Setup” on page 68
for further details.
• Record: To record the video within the specified time.
• No Recording: No scheduled recording.
5
Click a space on the grid to mark the schedule. The space changes color depending on the selected record type.
Click as many spaces as desired. Examples:
• To set motion detect recording, click the MOTION button, and then mark the schedule on the
grid. The marked schedule turns red.
• To set normal recording on a preset time, click the RECORD button, and then mark the schedule on the grid. The
marked schedule turns green.
• To remove the marked schedule, click the NO RECORDING button, and then mark the schedule on the grid. The
marked schedule turns white.
Motion detect recording
is set
Normal recording is set
No scheduled recording
