ENGLISH
Chapter 4: Using the DVR
DVR User’s Manual
41
4
Select an overwrite interval options (Auto/1 Hour/3 Hours/1 Day/7 Days/30 Days/90 Days/Close).
Note:
If the overwrite is set to Close, the recording will stop once the hard disk drive is full.
5
After all settings are complete, click Apply.
6
When data saving is complete, click OK.
Formatting HDD
After a new hard disk drive is properly installed in the DVR, the system automatically detects the HDD and prompts for
disk formatting.
To format the hard disk drive, do the following:
1
In preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu > DEVICE > HDD.
3
Select the hard disk drive that you want to format.
4
Click Format HDD.
5
An “All data will be deleted after formatting” warning message appears on the screen. Click OK to proceed.
6
When the formatting process is complete, click OK.
Formatting USB drive
To format the USB disk drive, do the following:
1
Plug a USB device into the USB connector at the front panel or the rear panel of the device.
2
In preview mode, right-click on the mouse to display the Pop-up menu.
3
Select Main Menu > DEVICE > HDD.
4
Click Format USB.
5
An “All data will be deleted after formatted” warning message appears on the screen. Click OK to proceed.
6
When the formatting process is complete, click OK.
Note:
Do not remove the USB device while drive formatting is in progress.
