ENGLISH
Chapter 4: Using the DVR
32
DVR User’s Manual
Color Setup
1
In preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu > DISPLAY.
3
On Channel, select the channel that you want to
change the color setting.
4
On Color, click Setup.
5
Drag the slider bar to adjust the color item setting.
6
After all settings are complete, click Apply.
7
When data saving is complete, click OK.
4.1.2 Recording Setup
With RECORD menu, you can customize the recording settings.
1
In preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu > RECORD.
3
Modify the necessary settings.
Menu item Description
Channel Select the channel that you want to configure.
Record Enable/Disable record mode.
Quality Set the video quality (Best/Fine/Normal).
Framerate Select the frame rate.
Resolution Select the recording resolution (CIF/D1).
Audio Turn the audio on/off.
Mode Select the record mode (Always/Schedule).
To record video the whole day (24 hours), select Always. To record the video at the
preset time, select Schedule (see
“Schedule Recording” on page 33 ).
Pack Time Set the elapsed time per recording (15 Min/30 Min/45 Min/60 Min).
Copy To Copy the current settings to all channels or one specific channel.
4
After all settings are complete, click Apply.
5
When data saving is complete, click OK.
