KGUARD Security TC801 - Manual (Page 14)

ENGLISH
Chapter 2: Installation
14
DVR User’s Manual
2.3.2 VGA Connection
Connect the video output of the DVR to the monitor via VGA connector as shown.
CH4 CH3 CH2 CH1
AIN4 AIN3 AIN2 AIN1
VIDEO OUT
VIDEO IN VIDEO IN
AUDIO OUT AUDIO IN
VGA
A B G
NETWORK RS485
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
AIN8 AIN7 AIN6 AIN5 AIN4 AIN3 AIN2 AIN1
VIDEO OUT
VIDEO IN VIDEO IN
AUDIO OUT AUDIO IN
VGA
A B G
NETWORK RS485
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
VGA
4-Channel DVR
8-Channel DVR
VGA cable
Monitor
2.4 Connecting the Cameras
Connect the camera cable(s) to the video input of the DVR via BNC or RS-485 connection.
2.4.1 BNC Connection
Connect the camera cable(s) to the video input of the DVR via BNC connector as shown.
CH4 CH3 CH2 CH1
AIN4 AIN3 AIN2 AIN1
VIDEO OUT
VIDEO IN VIDEO IN
AUDIO OUT AUDIO IN
VGA
A B G
NETWORK RS485
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CH4 CH3 CH2 CH1
VIDEO IN
4-Channel DVR
BNC cable
Camera
