ENGLISH
Chapter 4: Using the DVR
52
DVR User’s Manual
4.6.3 Video and Audio Settings
The VIDEO menu allows you to configure the video and audio output settings, including the setting of Privacy Zone
which is used to hide an area on the screen from being viewed.
Setting the Video Output
1
In preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu > SYSTEM > VIDEO.
3
Modify the necessary settings.
Menu Item Description
VGA
Resolution
Select the output resolution.
Video System Select the video system used in your location (NTSC/PAL).
Rotate Time
Set the interval time of changing screen display in Auto Switch mode. See “3.4.4 Auto
Switch View” on page 27 .
Privacy Zone Click to set the privacy zone. See “Setting the Privacy” on page 53.
4
Click Apply to save the video/audio settings.
5
When data saving is complete, click OK.
Setting the Volume
1
In preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu > SYSTEM > VIDEO.
3
Click Volume.
4
Drag the slider bar to adjust the output volume.
5
Click X to close the volume bar.
6
Click Apply to save volume settings.
7
When data saving is complete, click OK.
