8 AET_/PET_/ILT_NM-BA-e-1410
1.1. Balances AET-DM
AE-DM analytic balances
A – balance with d=0,01mg unit
B – balance with d=0,1mg unit
After balance installing at operating place,
following should be set:
1 – bottom ring
2 – balance pan
3 – pan shield
After the elements setting, additional
devices should be connected and balance
should be plugged to power source. Power
socket is located on back side of balance
housing.
Pipettes calibration
Remove the pan and put on its place:
- pipettes calibration chamber
- inside the chamber, pan and other
elements should be set up.
1.2. Balances AET series
Carefully remove the balance from its packaging, remove the plastic and foil
transport protective elements. Gently place the balance in its intended place of
use. Install the weighing pan, and other elements according to below scheme.
Analytical balances AET series
A – balance with reading unit
d=0,01mg
B – balance with reading unit
d=0,1mg
On installing the balance in its
intended place of use, assembly:
1 – bottom shield of the weighing
chamber
2 – centering ring
3 – weighing pan
4 – pan shield
On assembling all components,
connect peripheral devices to the
balance, and plug the balance to
mains. Power socket is located at the
back of balance’s housing.
