146 AET_/PET_/ILT_NM-BA-e-1410
28.3. TCP protocol settings
TCP, i.e.
Transmission Control Protocol
enables communicating two computers.
The TCP operates in client-server mode. The server pends for establishing a
connection on a specified port, and the client establishes connection with a
server.
Procedure of setting a port for “TCP” protocol:
−
Enter group of parameters < Communication>,
−
Select: „ Tcp / Port” which opens a window with on-screen
keyboard,
−
Insert required port number and accept by pressing key.
29. PERIPHERAL DEVICES
Menu PERIPHERAL DEVICES is located in menu group Parameters. It is
accessed by pressing Setup key or <
Setup > quick access key. Inside the
menu, there is a list of connectable peripheral devices, which can cooperate
with a balance.
29.1. Computer
Active connection between a balance and a computer is signaled by visible
pictogram
displayed in the upper bar of the main window. Submenu <
Computer> enables configuring connection settings.
Procedure:
− press key and “ Peripheral devices / Computer” key
− set balance’s parameters related to cooperation with a computer
− computer port
o
available options: none, COM 1, COM 2, Tcp
− address
o
give address of a balance which is connected to a computer
− continuous transmission
o
available options: NO, YES (printout format depends on set
printout template in a balance – see next parameter).
− weighing printout template
o
it is possible to design an individual printout to a computer using a
dedicated window with printout template. Principles on creating
printouts are described in point 27.16 of this user manual.
− E2R System
o
E2R System is a modular system performing complex operations of
supervision and control over all weighing processes carried out on
a balance. On enabling the option, the processes carried out on
some of the databases are carried out only from the computer level
(mode not available in balance’s standard version).
Caution:
Enabling parameter <
E2R System> can only be carried out by balance
manufacturer or authorized personnel.
