Maintenance Screens (cont)
DESCRIPTION
VALUE
UNITS
STATUS
FORCE
NAME
OMNIZONE::LMALM01: Supply air Sensor (Typical Limit Alarm)
Monitored Input Point
66.97
dF
Value
Alarm Inhibit Point
Off
Value
Limit Check
Alarm Status
Normal
Status
Alarm Value
0
dF
AlmValue
Exceeded Limit
0
dF
ExcdLim
Alarm Processor
Alarm Type
2
AlmType
Time of Last Message
15:08
LastTime
Month of Last Message
10
LastDate
Day of Last Message
26
LastDate
Year of Last Message
1
LastDate
Task Timer
4
sec
TaskTimr
OMNIZONE::DSP: Duct Static Pressure (Typical Milliamp Input)
System Value
0.2
in H2O
Sysvalue
Force
0
Force
Status
0
HwStat
Alarm Status
Normal
AlmStat
Sensor Value
0.2
in H2O
SenValue
Hardware Value
4.5
ma
HdwValue
Channel Number
2
ChanNum
Control Algorithm Name
ANCTL01
AlgoName
Alarm Algorithm Name
AlmName
OMNIZONE::ECONO: 2-position/Econo Valve (Typical Milliamp Output)
System Value
0
%
Sysvalue
Force
0
Force
Status
0
HwStat
Alarm Status
Normal
AlmStat
Control Value
0
%
CtrValue
Hardware Value
4
ma
HdwValue
Channel Number
27
ChanNum
Control Algorithm Name
CCVAV01
AlgoName
Alarm Algorithm Name
AlmName
OMNIZONE::OCCPC01: Occupancy 01
Time Schedule
Mode
0
Mode
Current Occupied Period
0
Period
Override in Progress
No
OverLast
Override Duration
0
min
OverDura
Occupied Start Time
0:00
OccStart
Unoccupied Start Time
0:00
UnStart
Next Occupied Day
NxtOccD
Next Occupied Time
0:00
NxtOccT
Next Unoccupied Day
NxtUnOD
Next Unoccupied Time
0:00
NxtUnOT
Last Unoccupied Day
Thu
PrvUnOD
Last Unoccupied Time
15:04
PrvUnOT
Push Button Override
Off
Value
Thermostat Override
0
dF
Value
Task Timer
1
sec
TaskTimr
OMNIZONE::BYPAS: VFD Bypass Enable (Typical)
System Value
Disable
Sysvalue
Force
0
Force
Status
0
HwStat
Alarm Status
Normal
AlmStat
Sensor Value
Disable
SenValue
Hardware Value
Open
HdwValue
Channel Number
23
ChanNum
Control Algorithm Name
AlgoName
Alarm Algorithm Name
AlmName
OMNIZONE::STPR_01: Supply Fan Speed
Analog Output Point
0
%
Value
Fan Status Point
Off
Value
Duct Static Pressure
0
in H2O
Value
Static Pressure Setpoint
0
in H2O
Value
PID_Master_Loop
Reference Output
0
%
RefOut
Proportional Term
0
%
PTerm
Integral Term
0
%
ITerm
Derivative Term
0
%
DTerm
Integrator Flags
0
Flags
Task Timer
0
sec
TaskTimr
