54
Configuration Screens (cont)
*Default values from factory.
NOTE: See CC6400 Comfort Controller Overview and Configuration Manual for configuration information.
DESCRIPTION VALUE* UNITS NAME
OMNIZONE::INTLK02: Ok to Cool
Discrete Output Point
COOLOK Name
Discrete Input Point 1 MODE Name
Discrete Input Point 2 SF_SFS Name
Discrete Interlock
Input 1 Comparison Off Sns1Sta
Input 2 Comparison On Sns2Sta
Off Persistence Time 3 sec OffPrst
On Persistence Time 10 sec OnPrst
Output Logic Type Normal LogType
Power on Delay 0 sec PowerUp
OMNIZONE::INTLK03: OK Fan + Sup. Fan Stat
Discrete Output Point
SF_SFS Name
Discrete Input Point 1 OKFAN Name
Discrete Input Point 2 SFS Name
Discrete Interlock
Input 1 Comparison On Sns1Sta
Input 2 Comparison On Sns2Sta
Off Persistence Time 2 sec OffPrst
On Persistence Time 2 sec OnPrst
Output Logic Type Normal LogType
Power on Delay 0 sec PowerUp
OMNIZONE::INTLK04: Supply Fan Delays
Discrete Output Point
SF Name
Discrete Input Point 1 OKFAN Name
Discrete Input Point 2 SENSDI00 Name
Discrete Interlock
Input 1 Comparison On Sns1Sta
Input 2 Comparison Off Sns2Sta
Off Persistence Time 300 sec OffPrst
On Persistence Time 20 sec OnPrst
Output Logic Type Normal LogType
Power on Delay 0 sec PowerUp
OMNIZONE::INTLK05: Dis. Cool befor SF delay
Discrete Output Point
FAN_CDWF Name
Discrete Input Point 1 CDWF Name
Discrete Input Point 2 OKFAN Name
Discrete Interlock
Input 1 Comparison On Sns1Sta
Input 2 Comparison On Sns2Sta
Off Persistence Time 3 sec OffPrst
On Persistence Time 3 sec OnPrst
Output Logic Type Normal LogType
Power on Delay 0 sec PowerUp
OMNIZONE::INTLK06: Activate VAV Terminals
Discrete Output Point
TRMCT Name
Discrete Input Point 1 OKFAN Name
Discrete Input Point 2 SF Name
Discrete Interlock
Input 1 Comparison Off Sns1Sta
Input 2 Comparison Off Sns2Sta
Off Persistence Time 1 sec OffPrst
On Persistence Time 1 sec OnPrst
Output Logic Type Invert LogType
Power on Delay 1 sec PowerUp
OMNIZONE::INTLK07: Ventilation Request
Discrete Output Point
VENTR Name
Discrete Input Point 1 TIMCLOCK Name
Discrete Input Point 2 SF_SFS Name
Discrete Interlock
Input 1 Comparison On Sns1Sta
Input 2 Comparison On Sns2Sta
Off Persistence Time 1 sec OffPrst
On Persistence Time 1 sec OnPrst
Output Logic Type Normal LogType
Power on Delay 1 sec PowerUp
OMNIZONE::INTLK08: Heat Interlock Relay
Discrete Output Point
HIR Name
Discrete Input Point 1 MODE Name
Discrete Input Point 2 SF_SFS Name
Discrete Interlock
Input 1 Comparison On Sns1Sta
Input 2 Comparison On Sns2Sta
Off Persistence Time 30 sec OffPrst
On Persistence Time 30 sec OnPrst
Output Logic Type Normal LogType
Power on Delay 5 sec PowerUp
