14
Table 7 — Controller Set Points
LEGEND
Check System Parameters — To check system
parameters, press the button. The LID display will
show: “Hardware Points Table 1.” Press to view the
hardware points. The user can navigate up and down through
the points with the up and down arrows.
Press 2 and to display the software points. The user
can navigate up and down through the points with the up and
down arrows.
Refer to Tables 8 and 9 for hardware and software points.
Display Alarm History — If the controller is indicating
there are alarms, the user can view the alarm history by
pressing the button. The LID display will show “Alarm
History.” Press . The LID display will show the date
and type of alarm.
As an example, if the LID display shows:
ALARM — 10:55 11-27-02
SFS
That display indicates that on 11/27/02 at 10:55 A.M. the
system Supply Fan was either on when it had not been
commanded on or was off when it was commanded on.
The user can view other stored alarms by pressing the up
and down arrows. The twenty-four most recent alarms are
stored.
Configure Custom Programming Selections —
To configure the custom programming selections, perform the
following procedure:
1. Press 37 . The LID display will show:
Custom Program
2. Press . The LID display will show:
2.0 Global Dictionary
OMNIZONE
3. Press . The display indicates “No Data.”
Press then press . Press
again. The LID display should now show:
Compressor Stages
4.00
4. Press 4 and then to indicate that 4 compressors
are installed.
5. Use the down and up arrows to select the other configura-
tion parameters as required. See Table 10 for a list of con-
figuration parameters.
6. A field-supplied 0 to 10 vdc signal to the 50XJ unit may
be used to reset the supply-air temperature.
The reset will be taken off the supply air set point
configured in the controller. The reset range can be
changed by adjusting the High Conversion Endpoint
value of the custom voltage input to a value other than
20. For example for 10 degrees of reset change the Hi
input value to 10. This may be found by pressing 7
from the Keypad. RESET will be the second
custom voltage input point in the controller. The first
will be CSMUX, which is the compressor status multi-
plexed input. Press
to see the following in the
LID display:
Ext. Supply Air Reset
RESET
Press
. If the LID display shows:
System Value
Press
. The LID display will show:
Low Input Endpoint
2.0 Volts
Press three times to get to the High Conversion
Endpoint. The user must be logged in to be able to change this
otherwise you can only view it. See the start up section for how
to log into the controller.
Configuration parameters are shown in Table 10.
DESCRIPTION
DISPLAY
SCREENS
VALUE UNITS STATUS FORCE NAME
OMNIZONE::SETPT01:
Supply fan Status
Occupied Lo Setpoint
0.3 in H2O OccLow
Occupied Hi Setpoint 0.4 in H2O OccHgh
Unoccupied Lo Setpoint 0.3 in H2O UnOccLow
Unoccupied Hi Setpoint 0.4 in H2O UnOccHgh
OMNIZONE::SETPT02:
VAVRESETbaseline
Occupied Lo Setpoint
0 dF OccLow
Occupied Hi Setpoint 0 dF OccHgh
Unoccupied Lo Setpoint 0 dF UnOccLow
Unoccupied Hi Setpoint 0 dF UnOccHgh
OMNIZONE::SETPT03:
Heat\Cool Mode & Reset
Occupied Lo Setpoint
70 dF OccLow
Occupied Hi Setpoint 74 dF OccHgh
Unoccupied Lo Setpoint 55 dF UnOccLow
Unoccupied Hi Setpoint 85 dF UnOccHgh
OMNIZONE::SETPT04:
Head Pressure Control
Occupied Lo Setpoint
225 PSIG OccLow
Occupied Hi Setpoint 225 PSIG OccHgh
Unoccupied Lo Setpoint 225 PSIG UnOccLow
Unoccupied Hi Setpoint 225 PSIG UnOccHgh
OMNIZONE::SETPT05:
Supply Static Pressure
Occupied Lo Setpoint
1.5 in H2O OccLow
Occupied Hi Setpoint 1.5 in H2O OccHgh
Unoccupied Lo Setpoint 1.5 in H2O UnOccLow
Unoccupied Hi Setpoint 1.5 in H2O UnOccHgh
OMNIZONE::SETPT06:
Supply Air Temperature
Occupied Lo Setpoint
55 dF OccLow
Occupied Hi Setpoint 55 dF OccHgh
Unoccupied Lo Setpoint 55 dF UnOccLow
Unoccupied Hi Setpoint 55 dF UnOccHgh
OMNIZONE::SETPT07:
Building Static Pressure
Occupied Lo Setpoint
0.02 in H2O OccLow
Occupied Hi Setpoint 0.02 in H2O OccHgh
Unoccupied Lo Setpoint 0.02 in H2O UnOccLow
Unoccupied Hi Setpoint 0.02 in H2O UnOccHgh
OMNIZONE::SETPT08:
BSP raw control
Occupied Lo Setpoint
12.32 ma OccLow
Occupied Hi Setpoint 12.32 ma OccHgh
Unoccupied Lo Setpoint 12.32 ma UnOccLow
Unoccupied Hi Setpoint 12.32 ma UnOccHgh
OMNIZONE::SETPT09:
Humidity Control
Occupied Lo Setpoint
0 %RH OccLow
Occupied Hi Setpoint 99 %RH OccHgh
Unoccupied Lo Setpoint 0 %RH UnOccLow
Unoccupied Hi Setpoint 99 %RH UnOccHgh
BSP — Building Static Pressure
RH — Relative Humidity
STAT
ENTER
STAT
HIST
ENTER
ALGO
ENTER
ENTER
CLEAR EXPN/EDIT
ENTER
ENTER
STAT
ENTER
EXPN/EDIT
