62
Maintenance Screens (cont)
DESCRIPTION VALUE UNITS STATUS FORCE NAME
OMNIZONE::HCVAV01: AO - Heating VAV 01
Heating Coil Valve
0 % Value
Fan Status Point Off Control Value
Sensor Group/SPT Sensor 74 dF Value
Occupied ? No Status
Space Setpoint 55 dF Value
High Humidity Switch Off Value
High Humidity Setpoint 99 %RH Value
High Humidity Sensor 49.56 %RH Value
Morning Warm Up
Reference Output Off RefOut
Morning Warmup ? FALSE HeatFlg
PID_Master_Loop
Reference Output 35 dF RefOut
Proportional Term 50.9 ^F PTerm
Integral Term 0 ^F ITerm
Derivative Term 0 ^F DTerm
Integrator Flags 100 FLAGS
HCV Supply Air Setpoint 35 dF HCVVRF
Supply Air Temperature 66.99 dF Value
P_Submaster_Loop
Reference Output 0 % RefOut
Proportional Term -96 % PropTerm
Submaster Flags 1 SubmFlag
Task Timer 1 sec TaskTimr
OMNIZONE::INTLK01: OK to run Fan (Typical Interlock)
Discrete Output Point
Off Value
Discrete Input Point 1 Off Value
Discrete Input Point 2 Off Value
Reference Output On RefOut
Task Timer 1 sec TaskTimr
OMNIZONE::LINK_01: Linkage/AOSS Schedule 01
Setpoint Bias
0 % Value
Adaptive Optimal Start
Start Bias 0 min StrtBias
Start Cool K Factor 10 CoolKFct
Start Heat K Factor 5 HeatKFct
Biased Start Day StartDay
Biased Start Time 0:00 BiasTim
Biased Occupied No BiasOcc
Cool Flag FALSE CoolFlg
Sensor Group/SPT Sensor 74 dF Value
Occupied ? No Status
Outside Air Temp 76.1 dF Value
Linkage Time Schedule
Mode 0 Mode
Biased Occupied 0 BiasFlag
Next Occupied Day NxtOcDay
Next Occupied Time 0:00 NxtOccT
Next Unoccupied Day NxtUnDay
Next Unoccupied Time 0:00 NxtUnoT
Last Unoccupied Day Thu PrvUnDay
Last Unoccupied Time 15:04 PrvUnoT
Status 0 Status
Override is set 0 Override
Linkage Setpt Schedule
Occupied Lo Setpoint 70 dF OccLow
Occupied Hi Setpoint 74 dF OccHgh
Unoccupied Lo Setpoint 55 dF UnoccLow
Unoccupied Hi Setpoint 85 dF UnoccHgh
Linkage Space Temp 74 dF Link
Supply Air Temp 66.97 dF Value
Fan Status Off Value
Air Side Linkage
Linkage Status 1 LinkStat
Supervisory Element 140 Supe-Adr
Supervisory Bus 0 Supe-Bus
Supervisory Block No. 3 BlockNum
Avg Occ Heat Setpoint 0 dF OcLoStpt
Avg Occ Cool Setpoint 0 dF OcHiStpt
Avg Unocc Heat Setpoint 0 dF UnLoStpt
Avg Unocc Cool Setpoint 0 dF UnHiStpt
Avg Zone Temperature 0 dF AZT
Avg Occ Zone Temp 0 dF AOZT
Adaptive Optimal Stop
Stop Bias 0 min StopBias
Stop Cool K Factor 10 CoolKFct
Stop Heat K Factor 15 HeatKFct
Biased Low Setpoint 70 dF BiasLow
Biased High Setpoint 74 dF BiasHigh
Biased Stop No AOStop
Cool Flag FALSE CoolFlg
Biased Stop Day BiasDay
Biased Stop Time 0:00 BiasTim
Task Timer 9 sec TaskTimr
Evacuation Off Evacuate
Pressurization Off Pressure
