Carrier OMNIZONE 50XJ064-104 - Manual (Page 59)

59
Maintenance Screens (cont)
DESCRIPTION VALUE UNITS STATUS FORCE NAME
OMNIZONE::ANCTL01: Supply Fan Status
Discrete Output Point
Off Control Value
Sensor Group/SPT Sensor 0.17 in H2O Value
Occupied ? No Status
Analog
Low Setpoint 0.3 in H2O LowSP
Lo Setpoint + Hyst 0 in H2O ModLowSP
Hi Setpoint - Hyst 0 in H2O ModHghSP
High Setpoint 0.4 in H2O HghSP
Reference Output FALSE RefOut
Task Timer 47 sec TaskTimr
OMNIZONE::ANCTL02: Humidity Control
Discrete Output Point
Off Value
Sensor Group/SPT Sensor 49.56 %RH Value
Occupied ? No Status
Analog
Low Setpoint 0 %RH LowSP
Lo Setpoint + Hyst 10 %RH ModLowSP
Hi Setpoint - Hyst 89 %RH ModHghSP
High Setpoint 99 %RH HghSP
Reference Output FALSE RefOut
Task Timer 25 sec TaskTimr
OMNIZONE::BSP_IN: Building Static Pressure (Typical Analog Software point)
System Value
0.03 in H2O Sysvalue
Force 0 Force
Status 0 Status
Alarm Status Normal AlmStat
OMNIZONE::CCVAV01: Modulating Economizer Control
Cooling Coil Valve
0 % Value
Fan Status Point Off Control Value
Sensor Group/SPT Sensor 0 dF Value
Occupied ? No Status
High Humidity Switch Off Value
High Humidity Setpoint 99 %RH Value
High Humidity Sensor 0 %RH Value
VAV Setpoint Reset
Setpoint 73 dF Setpoint
Setpoint Offset 20 ^F Offset
CCV Supply Air Setpoint 73 dF CCVVRF
Supply Air Temperature 77.19 dF Value
PID_Master_Loop
Reference Output 0 % RefOut
Proportional Term 0 % PTerm
Integral Term 0 % ITerm
Derivative Term 0 % DTerm
Integrator Flags 100 Flags
Task Timer 4 sec TaskTimr
OMNIZONE::BSP: Building Static Milliamp
System Value
12.4 ma Sysvalue
Force 0 Force
Status 0 HwStat
Alarm Status Normal AlmStat
Sensor Value 12.4 ma SenValue
Hardware Value 12.4 ma HwValue
Channel Number 34 ChanNum
Control Algorithm Name ADAPT03 AlgoName
Alarm Algorithm Name AlmName
OMNIZONE::IAQ: Indoor Air Quality
System Value
584.3 Sysvalue
Force 0 Force
Status 0 HwStat
Alarm Status Normal AlmStat
Sensor Value 584.3 SenValue
Hardware Value 8.7 ma HwValue
Channel Number 36 ChanNum
Control Algorithm Name AlgoName
Alarm Algorithm Name AlmName
OMNIZONE::CSMUX: Comp. Status MUX
System Value
1.83 Volts Sysvalue
Force 0 Force
Status 0 HwStat
Alarm Status Normal AlmStat
Sensor Value 1.83 Volts SenValue
Hardware Value 1.8 Volts HwValue
Channel Number 3 ChanNum
Control Algorithm Name AlgoName
Alarm Algorithm Name LMALM03 AlmName
