57
Configuration Screens (cont)
*Default values from factory.
NOTE: See CC6400 Comfort Controller Overview and Configuration Manual for configuration information.
DESCRIPTION VALUE* UNITS NAME
OMNIZONE::OCCPC01: Occupancy 01
Time Schedule
Manual Override Hours 0 hours Ovrd
Period 1: Day of Week 0 DOW1
Period 1: Occupied from 0:00 Occ1
Period 1: Occupied to 24:00:00 UnOcc1
Period 2: Day of Week 0 DOW2
Period 2: Occupied from 0:00 Occ2
Period 2: Occupied to 24:00:00 UnOcc2
Period 3: Day of Week 0 DOW3
Period 3: Occupied from 0:00 Occ3
Period 3: Occupied to 24:00:00 UnOcc3
Period 4: Day of Week 0 DOW4
Period 4: Occupied from 0:00 Occ4
Period 4: Occupied to 24:00:00 UnOcc4
Period 5: Day of Week 0 DOW5
Period 5: Occupied from 0:00 Occ5
Period 5: Occupied to 24:00:00 UnOcc5
Period 6: Day of Week 0 DOW6
Period 6: Occupied from 0:00 Occ6
Period 6: Occupied to 24:00:00 UnOcc6
Period 7: Day of Week 0 DOW7
Period 7: Occupied from 0:00 Occ7
Period 7: Occupied to 24:00:00 UnOcc7
Period 8: Day of Week 0 DOW8
Period 8: Occupied from 0:00 Occ8
Period 8: Occupied to 24:00:00 UnOcc8
Push Button Override LATCHI00 Name
Thermostat Override TEMP_I00 Name
Time Delay 5 min Value
Timed Override Duration 5 min Value
Power on Delay 0 sec PowerUp
OMNIZONE::STPR_01: Supply Fan Speed
Analog Output Point
SPEED
Fan Status Point SF
Duct Static Pressure DSP
Static Pressure Setpoint 1.5 in H2O
PID_Master_Loop
Proportional Gain 8
Integral Gain 4
Derivative Gain 0
Disabled Output Value 0 %
Minimum Output Value 10 %
Maximum Output Value 100 %
Starting Value 0 %
Block Iteration Rate 10 sec
Power on Delay 0 sec
OMNIZONE::TC01: DO - Time Clock 01
Discrete Output Point
TIMCLOCK Name
Time Schedule LINK_01 Name
Loadshed LDSHD00 Name
Duty Cycle
Duty Cycle Enable Disable Enable
First Minute of Hour 0 FirstOff
Second Minute of Hour 0 SecndOff
Occupied Off Duration 0 min OccOff
Unoccupied Off Duration 60 min UnOccOff
Minimum Off Time 3 min MinOff
Redline Bias Time 0 min BiasTime
Power on Delay 0 sec PowerUp
OMNIZONE::VPIOC: I/O & Faults
Compressor Status
Reschedule Rate 1 sec RESCHRAT
Power on Delay 10 sec RESCHPOR
Critical Fault
Reschedule Rate 2 sec RESCHRAT
Power on Delay 10 sec RESCHPOR
Fire Shutdown
Reschedule Rate 2 sec RESCHRAT
Power on Delay 10 sec RESCHPOR
Non Critical Fault
Reschedule Rate 2 sec RESCHRAT
Power on Delay 10 sec RESCHPOR
Compressor Fault/Test
Reschedule Rate 10 sec RESCHRAT
Power on Delay 30 sec RESCHPOR
