46
Configuration Screens (cont)
*Default values from factory.
NOTE: See CC6400 Comfort Controller Overview and Configuration Manual for configuration information.
DESCRIPTION VALUE* UNITS NAME
OMNIZONE::DOPI_01: Supply Fan Status
Discrete Output Point
SFS Name
Time Schedule OCCPC01 Name
Setpoint Schedule SETPT01 Name
Permissive Interlock
Control Point Type Analog Type
Occ Discrete State On OccSt
Unocc Discrete State On UnoccSt
Occ Analog Test Low OAnlgTst
Unocc Analog Test Low UAnlgTst
Override Value 0 Ovrd
Hysteresis 0.2 in H2O Hyst
Persistence Time 0 sec Persist
Analog Control Point DSP Name
Discrete Control Point PNT_NAME Name
Power on Delay 0 sec PowerUp
OMNIZONE::ANCTL02: Humidity Control
Discrete Output Point
DEHUM Name
Sensor Group/SPT Sensor IRH Name
Time Schedule LINK_01 Name
Setpoint Schedule SETPT09 Name
Analog
Hysteresis 10 %RH Hyst
Block Iteration Rate 60 sec BlkRate
Power on Delay 0 sec PowerUp
OMNIZONE::CCVAV01: Modulating Economizer Control
Cooling Coil Valve
ECONO Name
Fan Status Point ECON_OK Name
Sensor Group/SPT Sensor VAVRESET Name
Time Schedule LINK_01 Name
Setpoint Schedule SETPT02 Name
High Humidity Switch SENSDI00 Name
Humidity Setpoint SETPT00 Name
High Humidity Sensor MAMP_I00 Name
VAV Setpoint Reset
Supply Air Setpoint 53 dF Setpt
Reset Ratio 1 ^F RstRat
Start Reset 20 dF StrtRst
Maximum Reset 20 ^F MaxReset
Supply Air Temperature ECONPT Name
PID_Master_Loop
Proportional Gain -4 KP
Integral Gain -2 KI
Derivative Gain 0 KD
Disabled Output Value 0 % DsblOut
Minimum Output Value 0 % MinOut
Maximum Output Value 100 % MaxOut
Starting Value 30 % StartVal
Block Iteration Rate 30 sec BlkRate
Power on Delay 0 sec PowerUp
OMNIZONE::BSP: Building Static Milliamp
Low Input Endpoint
4 ma LowRange
High Input Endpoint 20 ma HighRng
Low Conversion Endpoint 4 ma LowConv
High Conversion Endpoint 20 ma HighConv
Low Input Fault 4 ma LowFlt
High Input Fault 20 ma HighFlt
Externally Powered No ExtPower
OMNIZONE::IAQ: Indoor Air Quality
Low Input Endpoint
4 ma LowRange
High Input Endpoint 20 ma HighRng
Low Conversion Endpoint 0 LowConv
High Conversion Endpoint 2000 HighConv
Low Input Fault 4 ma LowFlt
High Input Fault 20 ma HighFlt
Externally Powered Yes ExtPower
OMNIZONE::CSMUX: Comp. Status MUX
Low Input Endpoint
0 Volts LowRange
High Input Endpoint 11 Volts HighRng
Low Conversion Endpoint 0 Volts LowConv
High Conversion Endpoint 11 Volts HighConv
Low Input Fault 1 Volts LowFlt
High Input Fault 10.5 Volts HighFlt
