52
Configuration Screens (cont)
*Default values from factory.
NOTE: See CC6400 Comfort Controller Overview and Configuration Manual for configuration information.
DESCRIPTION VALUE* UNITS NAME
OMNIZONE::DSALM11: Compressor 4 Alarm
Monitored Input Point
C4_ALM Name
Comparison Point SENSDI00 Name
Alarm Inhibit Point SENSDI00 Name
Discrete Check
Alarm Logic Normal AlmLogic
Enable Delay Time 10 sec DlyTim
Persistence Time 10 sec Persist
Alarm Processor
Alarm Processing Enable AlmProc
Re-Alarm Interval 0 min ReAlmTim
Alarm=1 or Alert=0 1 Type
Alarm Level 2 AlmLevel
Alarm Source 5 AlmSrc
Alarm Routing 11010000 AlmRtg
Alarm Description Index 0 AlmDesc
Alarm Message - Part 1 Compressor 4 Fau Message
Alarm Message - Part 2 lt Message
Alarm Message - Part 3 Message
Alarm Message - Part 4 Message
Power on Delay 0 sec PowerUp
OMNIZONE::DSALM12: Supply Fan Alarm
Monitored Input Point
SFS Name
Comparison Point SF Name
Alarm Inhibit Point SENSDI00 Name
Discrete Check
Alarm Logic Normal AlmLogic
Enable Delay Time 120 sec DlyTim
Persistence Time 120 sec Persist
Alarm Processor
Alarm Processing Enable AlmProc
Re-Alarm Interval 0 min ReAlmTim
Alarm=1 or Alert=0 1 Type
Alarm Level 2 AlmLevel
Alarm Source 5 AlmSrc
Alarm Routing 11010000 AlmRtg
Alarm Description Index 0 AlmDesc
Alarm Message - Part 1 Check Supply Fan Message
Alarm Message - Part 2 Message
Alarm Message - Part 3 Message
Alarm Message - Part 4 Message
Power on Delay 0 sec PowerUp
OMNIZONE::DXVAV01: Compressor Staging
Discrete Output Point 1
CMP1 Name
Discrete Output Point 2 CMP2 Name
Discrete Output Point 3 CMP3 Name
Discrete Output Point 4 CMP4 Name
Discrete Output Point 5 DISCRO00 Name
Discrete Output Point 6 DISCRO00 Name
Fan Status Point COMPRES Name
Sensor Group/SPT Sensor VAVRESET Name
Time Schedule LINK_01 Name
Setpoint Schedule SETPT02 Name
High Humidity Switch SENSDI00 Name
Humidity Setpoint SETPT00 Name
High Humidity Sensor IRH Name
VAV Setpoint Reset
Supply Air Setpoint 57 dF SetPT
Reset Ratio 1 ^F RstRat
Start Reset 20 dF StrtRst
Maximum Reset 20 ^F MaxReset
Supply Air Temperature SAT Name
PID_Master_Loop
Proportional Gain -1 KP
Integral Gain -0.4 KI
Derivative Gain -0.7 KD
Disabled Output Value 0 % DsblOut
Minimum Output Value 0 % MinOut
Maximum Output Value 100 % MaxOut
Starting Value 0 % StartVal
Block Iteration Rate 30 sec BlkRate
Staging Control
Total Number of Stages 4 TotalStg
On Time Delay 2 min OnDelay
Off Time Delay 1 min OffDelay
Power on Delay 0 sec PowerUp
