APPENDIX B — CONTROL SCREENS
Display Screens
DESCRIPTION
VALUE
UNITS
STATUS
FORCE
NAME
OMNIZONE::HWP01-32:Hardware points Table 1
Supply Air Temperature
67
dF
SAT
Duct Static Pressure
0.2
in H2O
DSP
Comp. Status MUX
1.86
Volts
CSMUX
Fire Alarm/Shut Down
Enable
FSD
Cond. Water Flow Switch
Yes
CDWF
Remote Occupancy
Disable
ROCC
Duct High Press. Switch
Normal
DHS
Entering Water Temp.
69.9
dF
EWT
Compressor 1 Relay
Stop
CMP1
Compressor 2 Relay
Stop
CMP2
Compressor 3 Relay
Stop
CMP3
Compressor 4 Relay
Stop
CMP4
Supply Fan/VFD
Stop
SF
VFD Speed Signal
0
%
SPEED
Non Critical Fault
Off
WARN
Critical Fault
Off
ALARM
Mixed/Return Air Temp
77.2
dF
MA_RA
Dirty Filter Status
Clean
FLTS
Phase Loss Protection
Normal
PHASE
Ext. Supply Air Reset
0
dF
RESET
Water Econ. FreezeStat
Normal
FREEZ
Space_Reset Sensor
79.2
dF
SPT
VFD Bypass Enable
Disable
BYPAS
Head Pressure(Comp1)
118.76
PSIG
PRES
Ventilation Request
Close
VENTR
VAV Terminals Control
No
TRMCT
2-position/Econo Valve
0
%
ECONO
Reverse/Head Press Ctrl
100
%
Control
MVLV
Hot Water Valve
0
%
HWV
Heat Interlock Relay
Off
HIR
Bypass Start_Stop
Stop
BPS_S
VAV Terminals Open MAX
Close
TRMOP
OMNIZONE::HWP33-64: Hardware points table 2
Cooling Tower Sump Temp.
57.5
dF
TWR
Building Static Milliamp
12.51
ma
BSP
Condenser Leaving Water
70.3
dF
LWT
Indoor Air Quality
587.21
IAQ
Indoor Relative Humidity
49.7
%
IRH
Outdoor Air Temp.
76.1
dF
OAT
Heat Stage 1
Off
HEAT1
Heat Stage 2
Off
HEAT2
Heat Stage 3
Off
HEAT3
Heat Stage 4
Off
HEAT4
Pump Request
Off
PUMP
Cooling Tower Request
Off
TOWER
Exhaust Fan
0
%
EXH
Ext. Dehumidification
Stop
DEHUM
OMNIZONE::SWP65-96:Software Points
Compressor 1 Status
Off
CLO1
Compressor 2 Status
Off
CLO2
Compressor 3 Status
Off
CLO3
Compressor 4 Status
Off
CLO4
Bypass Acc Panel Secure
No
BP_SAFE
DX VAV RESET Control
0
dF
VAVRESET
Factory/Field Test
Stop
FLDTST
Building Static Pressure
0.03
in H2O
BSP_IN
Time Clock
Off
TIMCLOCK
Cooling
Disable
COOLOK
Supply Fan Status
Off
Control
SFS
Ok to run Fan
No
OKFAN
OK Fan + Sup. Fan Stat
FALSE
SF_SFS
Fan + Cond. Water Flow
FALSE
FAN_CDWF
Equipment Mode
Cool
Control
MODE
Activate Evacuation Mode
Disable
EVAC
Space Control Point
74
dF
CTRLPT
Mod. Econ Enabled
No
Control
ECON_OK
Head Pressure Control
Disable
Control
HEAD
Economizer Control Temp.
77.22
dF
ECONPT
Compressor Cooling
Disable
COMPRES
Duct Static Failure
Normal
DSP_ALM
Compressor 1 Alarm
Normal
C1_ALM
Compressor 2 Alarm
Normal
C2_ALM
Compressor 3 Alarm
Normal
C3_ALM
Compressor 4 Alarm
Normal
C4_ALM
Cond. Flow Alarm Status
Disable
Control
CDWF_ST
