Maintenance Screens (cont)
DESCRIPTION
VALUE
UNITS
STATUS
FORCE
NAME
OMNIZONE::PRES: Head Pressure(Comp1)
System Value
118.76
PSIG
Sysvalue
Force
0
Force
Status
0
HwStat
Alarm Status
Normal
AlmStat
Sensor Value
118.76
PSIG
SenValue
Hardware Value
1.9
Volts
HwValue
Channel Number
24
ChanNum
Control Algorithm Name
ADAPT02
AlgoName
Alarm Algorithm Name
AlmName
OMNIZONE::RESET: Ext. Supply Air Reset
System Value
0
dF
Sysvalue
Force
0
Force
Status
0
HwStat
Alarm Status
Normal
AlmStat
Sensor Value
0
dF
SenValue
Hardware Value
1.1
Volts
HwValue
Channel Number
20
ChanNum
Control Algorithm Name
ADAPT01
AlgoName
Alarm Algorithm Name
AlmName
OMNIZONE::UPDATEDB: Database Control
Database Error
No
DBError
EEPROM Error
No
EEError
RAM Error
No
RAMError
Available Program Bytes
11130
EEPROM
Available Data Bytes
14742
RAM
OMNIZONE::ALARM: Critical Fault (Typical Discrete Out)
System Value
Off
SysVal
Force
0
Force
Status
0
HwStat
Alarm Status
Normal
AlmStat
Control Value
Off
CtrValue
Hardware Value
Open
HdwValue
Channel Number
16
ChanNum
Control Algorithm Name
AlgoName
Alarm Algorithm Name
AlmName
OMNIZONE::BP_SAFE: Bypass Acc Panel Secure (Typical Discrete Software)
System Value
No
Sysvalue
Force
0
Force
Status
0
Status
Alarm Status
Normal
AlmStat
OMNIZONE::DOPI_01: Supply Fan Status
Discrete Output Point
Off
Control
Value
Occupied ?
No
Status
Permissive Interlock
Reference Output
0
RefOut
Perm Interlock Flag
TRUE
PIFlag
Conditional
Low
Condtion
Modified Setpoint
0.5
in H2O
ModStpt
Persistence Timer
0
sec
PersTime
Setpoint Limit
0.3
in H2O
Value
Analog Control Point
0.17
in H2O
Value
Discrete Control Point
Off
Value
Task Timer
1
sec
TaskTimr
OMNIZONE::DSALM01: Duct High Pressure (Typical Discrete Alarm)
Monitored Input Point
Off
Value
Comparison Point
Off
Value
Alarm Inhibit Point
Off
Value
Alarm Status
Normal
Status
Alarm Processor
Alarm Type
0
AlmType
Time of Last Message
0:00
LastTime
Month of Last Message
0
LastDate
Day of Last Message
0
LastDate
Year of Last Message
0
LastDate
Task Timer
2
sec
TaskTimr
