Display Screens (cont)
DESCRIPTION
VALUE
UNITS
STATUS
FORCE
NAME
OMNIZONE:Custom Configuration
Compressor Stages
2
NUM_CMP
Reset Ratio
3
dF
RSET_RTO
CDWF 0=NO,1=YES
0
CDFW_SWT
ECON 0=NO,1=YES
0
EWT_SNS
EWT Reset 0=NO,1=YES
1
EWT_RST
MOD.VLV 0=NO,1=YES
0
MOD_ECON
0=CONST.,1=VARIABLE
0
FLOW_TYP
0=RAT,1=MAT,2=NONE
2
MARA_SNS
PHASE 0=NO,1=YES
0
PHAS_SWT
FREEZ 0=NO,1=YES
0
FREZ_SWT
ENABLE ECON.
68
dF
ECON_SET
SPT 0=NO,1=YES
0
SPT_SNS
PRES 0=NO,1=YES
0
SPT_SNS
TWR 0=NO,1=YES
0
TWR_SNS
LWT 0=NO,1=YES
0
LWT_SNS
IAQ 0=NO,1=YES
0
IAQ_SNS
IRH 0=NO,1=YES
0
IRH_SNS
BSP 0=NO,1=YES
0
BSP_SNS
BSP Range
1.00
in H2O
BSP_RNG
BSP LOW VALUE
-0.5
in H2O
BSP_LOW
Setpoints
OMNIZONE::SETPT01: Supply fan Status
Occupied Lo Setpoint
0.3
in H2O
OccLow
Occupied Hi Setpoint
0.4
in H2O
OccHgh
Unoccupied Lo Setpoint
0.3
in H2O
UnOccLow
Unoccupied Hi Setpoint
0.4
in H2O
UnOccHgh
OMNIZONE::SETPT02: VAVRESETbaseline
Occupied Lo Setpoint
0
dF
OccLow
Occupied Hi Setpoint
0
dF
OccHgh
Unoccupied Lo Setpoint
0
dF
UnOccLow
Unoccupied Hi Setpoint
0
dF
UnOccHgh
OMNIZONE::SETPT03: Heat\Cool Mode & Reset
Occupied Lo Setpoint
70
dF
OccLow
Occupied Hi Setpoint
74
dF
OccHgh
Unoccupied Lo Setpoint
55
dF
UnOccLow
Unoccupied Hi Setpoint
85
dF
UnOccHgh
OMNIZONE::SETPT04: Head Pressure Control
Occupied Lo Setpoint
225
PSIG
OccLow
Occupied Hi Setpoint
225
PSIG
OccHgh
Unoccupied Lo Setpoint
225
PSIG
UnOccLow
Unoccupied Hi Setpoint
225
PSIG
UnOccHgh
OMNIZONE::SETPT05: Supply Static Pressure
Occupied Lo Setpoint
1.5
in H2O
OccLow
Occupied Hi Setpoint
1.5
in H2O
OccHgh
Unoccupied Lo Setpoint
1.5
in H2O
UnOccLow
Unoccupied Hi Setpoint
1.5
in H2O
UnOccHgh
OMNIZONE::SETPT06: Supply Air Temperature
Occupied Lo Setpoint
55
dF
OccLow
Occupied Hi Setpoint
55
dF
OccHgh
Unoccupied Lo Setpoint
55
dF
UnOccLow
Unoccupied Hi Setpoint
55
dF
UnOccHgh
OMNIZONE::SETPT07: Building Static Pressure
Occupied Lo Setpoint
0.02
in H2O
OccLow
Occupied Hi Setpoint
0.02
in H2O
OccHgh
Unoccupied Lo Setpoint
0.02
in H2O
UnOccLow
Unoccupied Hi Setpoint
0.02
in H2O
UnOccHgh
OMNIZONE::SETPT08: BSP raw control
Occupied Lo Setpoint
12.32
ma
OccLow
Occupied Hi Setpoint
12.32
ma
OccHgh
Unoccupied Lo Setpoint
12.32
ma
UnOccLow
Unoccupied Hi Setpoint
12.32
ma
UnOccHgh
OMNIZONE::SETPT09: Humidity Control
Occupied Lo Setpoint
0
%RH
OccLow
Occupied Hi Setpoint
99
%RH
OccHgh
Unoccupied Lo Setpoint
0
%RH
UnOccLow
Unoccupied Hi Setpoint
99
%RH
UnOccHgh
