49
Configuration Screens (cont)
*Default values from factory.
NOTE: See CC6400 Comfort Controller Overview and Configuration Manual for configuration information.
DESCRIPTION VALUE* UNITS NAME
OMNIZONE::DSALM02: Phase Protection
Monitored Input Point
PHASE Name
Comparison Point SENSDI00 Name
Alarm Inhibit Point SENSDI00 Name
Discrete Check
Alarm Logic Normal AlmLogic
Enable Delay Time 15 sec DlyTim
Persistence Time 10 sec Persist
Alarm Processor
Alarm Processing Enable AlmProc
Re-Alarm Interval 0 min ReAlmTim
Alarm=1 or Alert=0 1 Type
Alarm Level 1 AlmLevel
Alarm Source 5 AlmSrc
Alarm Routing 11010000 AlmRtg
Alarm Description Index 0 AlmDesc
Alarm Message - Part 1 Phase Loss Message
Alarm Message - Part 2 Message
Alarm Message - Part 3 Message
Alarm Message - Part 4 Message
Power on Delay 0 sec PowerUp
OMNIZONE::DSALM03: Freeze Protection
Monitored Input Point
FREEZ Name
Comparison Point SENSDI00 Name
Alarm Inhibit Point SENSDI00 Name
Discrete Check
Alarm Logic Normal AlmLogic
Enable Delay Time 15 sec DlyTim
Persistence Time 900 sec Persist
Alarm Processor
Alarm Processing Enable AlmProc
Re-Alarm Interval 0 min ReAlmTim
Alarm=1 or Alert=0 1 Type
Alarm Level 1 AlmLevel
Alarm Source 5 AlmSrc
Alarm Routing 11010000 AlmRtg
Alarm Description Index 0 AlmDesc
Alarm Message - Part 1 Economizer Freez Message
Alarm Message - Part 2 e Condition Message
Alarm Message - Part 3 Message
Alarm Message - Part 4 Message
Power on Delay 0 sec PowerUp
OMNIZONE::DSALM04: Duct Static Failure
Monitored Input Point
DSP_ALM Name
Comparison Point SENSDI00 Name
Alarm Inhibit Point SENSDI00 Name
Discrete Check
Alarm Logic Normal AlmLogic
Enable Delay Time 10 sec DlyTim
Persistence Time 10 sec Persist
Alarm Processor
Alarm Processing Enable AlmProc
Re-Alarm Interval 0 min ReAlmTim
Alarm=1 or Alert=0 1 Type
Alarm Level 1 AlmLevel
Alarm Source 5 AlmSrc
Alarm Routing 11010000 AlmRtg
Alarm Description Index 0 AlmDesc
Alarm Message - Part 1 Duct Static Sens Message
Alarm Message - Part 2 or Failure Message
Alarm Message - Part 3 Message
Alarm Message - Part 4 Message
Power on Delay 0 sec PowerUp
