61
Maintenance Screens (cont)
DESCRIPTION VALUE UNITS STATUS FORCE NAME
OMNIZONE::DXVAV01: Compressor Staging
Discrete Output Point 1
Off Value
Discrete Output Point 2 Off Value
Discrete Output Point 3 Off Value
Discrete Output Point 4 Off Value
Discrete Output Point 5 Off Value
Discrete Output Point 6 Off Value
Fan Status Point Off Value
Sensor Group/SPT Sensor 0 dF Value
Occupied ? No Status
High Humidity Switch Off Value
High Humidity Setpoint 99 %RH Value
High Humidity Sensor 49.56 %RH Value
VAV Setpoint Reset
Setpoint 75 dF Setpoint
Setpoint Offset 20 ^F Offset
DX Supply Air Setpoint 75 dF DODXRF
Supply Air Temperature 66.97 dF Value
PID_Master_Loop
Reference Output 0 % RefOut
Proportional Term 11.9 % PTerm
Integral Term 0 % ITerm
Derivative Term 0 % DTerm
Integrator Flags 100 Flags
Staging Control
Number of Stages 0 NumStgs
Requested Stages 0 ReqStgs
Delta Stages 0 DltaStgs
Delay Timer 0 min DlyTimer
PID Integrator Clamp Off PIDClamp
Task Timer 4 sec TaskTimr
OMNIZONE::EHVAV01: DO - Elec Heat VAV 01
Discrete Output Point 1
Off Value
Discrete Output Point 2 Off Value
Discrete Output Point 3 Off Value
Discrete Output Point 4 Off Value
Discrete Output Point 5 Off Value
Discrete Output Point 6 Off Value
Fan Status Point Off Control Value
Sensor Group/SPT Sensor 74 dF Value
Occupied ? No Status
High Humidity Switch Off Value
High Humidity Setpoint 99 %RH Value
High Humidity Sensor 49.71 %RH Value
Duct Temperature 66.97 dF Value
Duct High Limit 150 dF Value
Morning Warm Up
Reference Output Off RefOut
Morning Warmup ? FALSE HeatFlg
PID_Master_Loop
Reference Output 0 % RefOut
Proportional Term 84.9 % PTerm
Integral Term 0 % ITerm
Derivative Term 0 % DTerm
Integrator Flags 100 Flags
Space Setpoint 55 dF Value
Staging Control
Number of Stages 0 NumStgs
Requested Stages 0 ReqStgs
Delta Stages 0 DltaStgs
Delay Timer 0 min DlyTimer
PID Integrator Clamp Off PIDClamp
Task Timer 7 sec TaskTimr
