45
Configuration Screens
*Default values from factory.
NOTE: See CC6400 Comfort Controller Overview and Configuration Manual for configuation information.
DESCRIPTION VALUE* UNITS NAME
OMNIZONE::CC6400:Controller Identification
Description: OMNIZONE VPAC DevDesc
Location: Test Version 0.009 Location
Software Part Number: CEPP-130124-07 PartNum
Model Number: 6400 ModelNum
Serial Number: SerialNo
Reference Number: Version 1.6 RefNum
OMNIZONE::ADAPT01: VAVRESET Software point con-
trol
Analog Output Point
VAVRESET Name
Status Point COOLOK Name
Time Schedule LINK_01 Name
Setpoint Schedule SETPT02 Name
Reset Point TEMP_I00 Name
Reset
Start Reset Value -40 dF StrtRst
Stop Reset Value 245 dF StopRst
Control Point RESET Name
PID_Master_Loop
Proportional Gain 1 KP
Integral Gain 0 KI
Derivative Gain 0 KD
Disabled Output Value 0 % DsblOut
Minimum Output Value 0 % MinOut
Maximum Output Value 20 % MaxOut
Starting Value 20 % StartVal
Block Iteration Rate 10 sec BlkRate
Power on Delay 0 sec PowerUp
OMNIZONE::ADAPT02: Head Pressure control
Analog Output Point
MVLV Name
Status Point HEAD Name
Time Schedule LINK_01 Name
Setpoint Schedule SETPT04 Name
Reset Point TEMP_I00 Name
Reset
Start Reset Value -40 PSIG StrtRst
Stop Reset Value 245 PSIG StopRst
Control Point PRES Name
PID_Master_Loop
Proportional Gain -0.2 KP
Integral Gain -0.1 KI
Derivative Gain -0.1 KD
Disabled Output Value 0 % DsblOut
Minimum Output Value 40 % MinOut
Maximum Output Value 100 % MaxOut
Starting Value 100 % StartVal
Block Iteration Rate 10 sec BlkRate
Power on Delay 0 sec PowerUp
OMNIZONE::ADAPT03: Building Pressure Ctrl.
Analog Output Point
EXH Name
Status Point OKFAN Name
Time Schedule LINK_01 Name
Setpoint Schedule SETPT08 Name
Reset Point TEMP_I00 Name
Reset
Start Reset Value -40 ma StrtRst
Stop Reset Value 245 ma StopRst
Control Point BSP Name
PID_Master_Loop
Proportional Gain -20 KP
Integral Gain -10 KI
Derivative Gain 0 KD
Disabled Output Value 0 % DsblOut
Minimum Output Value 0 % MinOut
Maximum Output Value 100 % MaxOut
Starting Value 40 % StartVal
Block Iteration Rate 10 sec BlkRate
Power on Delay 0 sec PowerUp
OMNIZONE::ANCTL01: Supply Fan Status
Discrete Output Point
SFS Name
Sensor Group/SPT Sensor DSP Name
Time Schedule OCCPC01 Name
Setpoint Schedule SETPT01 Name
Analog
Hysteresis 0 in H2O Hyst
Block Iteration Rate 30 sec BlkRate
Power on Delay 0 sec PowerUp
