55
Configuration Screens (cont)
*Default values from factory.
NOTE: See CC6400 Comfort Controller Overview and Configuration Manual for configuration information.
DESCRIPTION VALUE* UNITS NAME
OMNIZONE::INTLK09: Condenser Pump
Discrete Output Point
PUMP Name
Discrete Input Point 1 COOLOK Name
Discrete Input Point 2 SENSDI00 Name
Discrete Interlock
Input 1 Comparison On Sns1Sta
Input 2 Comparison Off Sns2Sta
Off Persistence Time 30 sec OffPrst
On Persistence Time 2 sec OnPrst
Output Logic Type Normal LogType
Power on Delay 0 sec PowerUp
OMNIZONE::INTLK10: Tower Request
Discrete Output Point
TOWER Name
Discrete Input Point 1 COOLOK Name
Discrete Input Point 2 SENSDI00 Name
Discrete Interlock
Input 1 Comparison On Sns1Sta
Input 2 Comparison Off Sns2Sta
Off Persistence Time 30 sec OffPrst
On Persistence Time 2 sec OnPrst
Output Logic Type Normal LogType
Power on Delay 0 sec PowerUp
OMNIZONE::INTLK11: Compressor Cooling
Discrete Output Point
COMPRES Name
Discrete Input Point 1 COOLOK Name
Discrete Input Point 2 FAN_CDWF Name
Discrete Interlock
Input 1 Comparison On Sns1Sta
Input 2 Comparison On Sns2Sta
Off Persistence Time 2 sec OffPrst
On Persistence Time 30 sec OnPrst
Output Logic Type Normal LogType
Power on Delay 0 sec PowerUp
OMNIZONE::LINK_01: Linkage/AOSS Schedule 01
Setpoint Bias
VOLT_I00 Name
Setpoint Schedule SETPT03 Name
Adaptive Optimal Start
AO Start Enable Disable Enable
Building Insulation 30 BldInsul
Unoccupied 24hr Factor 15 UnOccFct
Offset Low Value 0 ^F Value
Offset High Value 0 ^F Value
Sensor Group/SPT Sensor CTRLPT Name
Time Schedule OCCPC01 Name
Outside Air Temp OAT Name
NTFC Algorithm NTFC_00 Name
Heating Algorithm HCVAV01 Name
Supply Air Temp SAT Name
Fan Status SF_SFS Name
Adaptive Optimal Stop
AO Stop Enable Disable Enable
Maximum Stop Time 60 min MaxStop
Setpoint Bias 2 ^F SPBias
Power on Delay 0 sec PowerUp
Evacuation EVAC Evacuate
Pressurization TRMOP Pressure
OMNIZONE::LMALM01: Supply air Sensor
Monitored Input Point
SAT Name
Alarm Inhibit Point SENSDI00 Name
Limit Check
Low Limit 25 dF LowLim
High Limit 150 dF HighLim
Enable Delay Time 15 sec DlyTim
Persistence Time 10 sec Persist
Hysteresis 5 ^F Hyst
Alarm Processor
Alarm Processing Enable AlmProc
Re-Alarm Interval 0 min ReAlmTim
Alarm=1 or Alert=0 1 Type
Alarm Level 1 AlmLevel
Alarm Source 5 AlmSrc
Alarm Routing 11010000 AlmRtg
Alarm Description Index 7 AlmDesc
Alarm Message - Part 1 Message
Alarm Message - Part 2 Message
Alarm Message - Part 3 Message
Alarm Message - Part 4 Message
Power on Delay 0 sec PowerUp
