53
Configuration Screens (cont)
*Default values from factory.
NOTE: See CC6400 Comfort Controller Overview and Configuration Manual for configuration information.
DESCRIPTION VALUE* UNITS NAME
OMNIZONE::EHVAV01: DO - Elec Heat VAV 01
Discrete Output Point 1
HEAT1 Name
Discrete Output Point 2 HEAT2 Name
Discrete Output Point 3 HEAT3 Name
Discrete Output Point 4 HEAT4 Name
Discrete Output Point 5 DISCRO00 Name
Discrete Output Point 6 DISCRO00 Name
Fan Status Point MODE Name
Sensor Group/SPT Sensor LINK_09 Name
Time Schedule LINK_01 Name
Setpoint Schedule LINK_01 Name
High Humidity Switch SENSDI00 Name
Humidity Setpoint SETPT00 Name
High Humidity Sensor IRH Name
Duct Temperature SAT Name
Duct High Limit 150 dF Value
Occupied Heating Yes OccHeat
PID_Master_Loop
Proportional Gain 5 KP
Integral Gain 2.5 KI
Derivative Gain 0 KD
Disabled Output Value 0 % DdblOut
Minimum Output Value 0 % MinOut
Maximum Output Value 100 % MaxOut
Starting Value 0 % StartVAl
Block Iteration Rate 15 sec BlkRate
Heating Setpoint Offset 3 ^F Value
Staging Control
Total Number of Stages 4 TotalStg
On Time Delay 3 min OnDelay
Off Time Delay 1 min OffDelay
Power on Delay 0 sec PowerUp
OMNIZONE::HCVAV01: AO - Heating VAV 01
Heating Coil Valve
HWV Name
Fan Status Point MODE Name
Sensor Group/SPT Sensor LINK_09 Name
Time Schedule LINK_01 Name
Setpoint Schedule LINK_01 Name
Heating Setpoint Offset 3 ^F Value
High Humidity Switch SENSDI00 Name
Humidity Setpoint SETPT00 Name
High Humidity Sensor IRH Name
Occupied Heating Yes OccHeat
PID_Master_Loop
Proportional Gain 3 KP
Integral Gain 1.5 KI
Derivative Gain 0 KD
Disabled Output Value 35 dF DsblOut
Minimum Output Value 40 dF MinOut
Maximum Output Value 140 dF MaxOut
Starting Value 80 dF StartVal
Block Iteration Rate 15 sec BlkRate
Supply Air Temperature SAT Name
P_Submaster_Loop
Proportional Gain 3 KP
Disabled Output Value 0 % FanOff
Minimum Output Value 0 % MinOut
Maximum Output Value 100 % MaxOut
Center Value 30 % Center
Block Iteration Rate 2 sec BlkRate
Power on Delay 0 sec PowerUp
OMNIZONE::INTLK01: OK to run Fan
Discrete Output Point
OKFAN Name
Discrete Input Point 1 TIMCLOCK Name
Discrete Input Point 2 ROCC Name
Discrete Interlock
Input 1 Comparison Off Sns1Sta
Input 2 Comparison Off Sns2Sta
Off Persistence Time 5 sec OffPrst
On Persistence Time 5 sec OnPrst
Output Logic Type Invert LogType
Power on Delay 5 sec PowerUp
