50
Configuration Screens (cont)
*Default values from factory.
NOTE: See CC6400 Comfort Controller Overview and Configuration Manual for configuration information.
DESCRIPTION VALUE* UNITS NAME
OMNIZONE::DSALM05: Fire alarm
Monitored Input Point
FSD Name
Comparison Point SENSDI00 Name
Alarm Inhibit Point SENSDI00 Name
Discrete Check
Alarm Logic Invert AlmLogic
Enable Delay Time 10 sec DlyTim
Persistence Time 10 sec Persist
Alarm Processor
Alarm Processing Enable AlmProc
Re-Alarm Interval 0 min ReAlmTim
Alarm=1 or Alert=0 1 Type
Alarm Level 0 AlmLevel
Alarm Source 5 AlmSrc
Alarm Routing 11010000 AlmRtg
Alarm Description Index 0 AlmDesc
Alarm Message - Part 1 Fire Shutdown Message
Alarm Message - Part 2 Message
Alarm Message - Part 3 Message
Alarm Message - Part 4 Message
Power on Delay 0 sec PowerUp
OMNIZONE::DSALM06: Condenser Water Flow
Monitored Input Point
CDWF Name
Comparison Point COOLOK Name
Alarm Inhibit Point CDWF_ST Name
Discrete Check
Alarm Logic Normal AlmLogic
Enable Delay Time 120 sec DlyTim
Persistence Time 120 sec Persist
Alarm Processor
Alarm Processing Enable AlmProc
Re-Alarm Interval 0 min ReAlmTim
Alarm=1 or Alert=0 1 Type
Alarm Level 2 AlmLevel
Alarm Source 5 AlmSrc
Alarm Routing 11010000 AlmRtg
Alarm Description Index 0 AlmDesc
Alarm Message - Part 1 Check Condenser Message
Alarm Message - Part 2 Water Flow Message
Alarm Message - Part 3 Message
Alarm Message - Part 4 Message
Power on Delay 0 sec PowerUp
OMNIZONE::DSALM07: Filter Alarm
Monitored Input Point
FLTS Name
Comparison Point SENSDI00 Name
Alarm Inhibit Point SENSDI00 Name
Discrete Check
Alarm Logic Normal AlmLogic
Enable Delay Time 10 sec DlyTim
Persistence Time 20 sec Persist
Alarm Processor
Alarm Processing Enable AlmProc
Re-Alarm Interval 0 min ReAlmTim
Alarm=1 or Alert=0 1 Type
Alarm Level 2 AlmLevel
Alarm Source 5 AlmSrc
Alarm Routing 11010000 AlmRtg
Alarm Description Index 0 AlmDesc
Alarm Message - Part 1 Change Filters Message
Alarm Message - Part 2 Message
Alarm Message - Part 3 Message
Alarm Message - Part 4 Message
Power on Delay 0 sec PowerUp
