Chapter 3: EIU datafill 93
DMS-100 Family EIU User Guide TELECOM12
Sample datafill for table IPTHRON
Figure 19 shows sample datafill for table IPTHRON for an EIU.
Figure 19 Datafill example for table IPTHRON
Table IPPROTO
Table IPPROTO is rarely used and normally does not need to be datafilled.
EIUINDEX 0 to 750 Ethernet interface unit index
If the entry in field SNNODE is EIU,
enter the EIU index.
Go to refinement TXCAPCT.
ELIUINDEX 0 to 750 Ethernet link interface unit index
If the entry in field SNNODE is ELIU,
enter the ELIU index.
Go to refinement TXCAPCT.
MSINDEX 0 to 1 Message switch index
If the entry in field SNNODE is MS,
enter the MS index.
Go to refinement TXCAPCT.
TXCAPCT 0 to 32767 Transmit capacity
Enter the IP transmission rate in kilobits
per second from node to node. The
node name and number are specified
as a key to this tuple.
Table 22 Field descriptions for table IPTHRON for EIU datafill (continued)
Field Subfield or
refinement Entry Explanation and action
(Sheet 3 of 3)
LMSNODE TXCAPCT RXCAPCT
OPTION
-------------------------------------------------------------------------------
EIU 117 15 15 $
